AWS SQS and SNS Patterns in 2026: Fan-Out, FIFO Queues, and Message Filtering

SQS and SNS are the backbone of async messaging on AWS. SQS decouples producers from consumers and handles retries, backpressure, and dead-letter queues. SNS broadcasts a single event to multiple subscribers — the fan-out pattern. Together they enable event-driven architectures that scale independently.

This post covers the patterns teams actually need: SNS fan-out to multiple SQS queues, FIFO queues for ordered processing, subscription filter policies to route messages, Lambda trigger configuration, DLQ setup, and Terraform for all of it.

---

SQS Alone: Decoupling a Single Consumer

// lib/aws/sqs-client.ts
import {
  SQSClient,
  SendMessageCommand,
  ReceiveMessageCommand,
  DeleteMessageCommand,
  ChangeMessageVisibilityCommand,
} from "@aws-sdk/client-sqs";

const sqs = new SQSClient({ region: process.env.AWS_REGION });
const QUEUE_URL = process.env.SQS_QUEUE_URL!;

// Producer: send a message
export async function enqueueJob(payload: object, deduplicationId?: string) {
  await sqs.send(new SendMessageCommand({
    QueueUrl: QUEUE_URL,
    MessageBody: JSON.stringify(payload),
    // For FIFO queues:
    MessageGroupId: "default",            // Messages in same group are ordered
    MessageDeduplicationId: deduplicationId, // Prevents duplicates within 5 min
    // MessageAttributes for metadata without touching body:
    MessageAttributes: {
      eventType: { DataType: "String", StringValue: "order.created" },
      version: { DataType: "Number", StringValue: "1" },
    },
  }));
}

// Consumer: poll and process
export async function processMessages(handler: (body: unknown) => Promise<void>) {
  while (true) {
    const result = await sqs.send(new ReceiveMessageCommand({
      QueueUrl: QUEUE_URL,
      MaxNumberOfMessages: 10,          // Batch up to 10
      WaitTimeSeconds: 20,              // Long polling — reduces empty receives
      VisibilityTimeout: 30,            // 30s to process before message reappears
      AttributeNames: ["ApproximateReceiveCount"],
    }));

    if (!result.Messages?.length) continue;

    await Promise.allSettled(
      result.Messages.map(async (message) => {
        const body = JSON.parse(message.Body!);
        const receiveCount = parseInt(
          message.Attributes?.ApproximateReceiveCount ?? "1", 10
        );

        try {
          await handler(body);
          // Delete on success
          await sqs.send(new DeleteMessageCommand({
            QueueUrl: QUEUE_URL,
            ReceiptHandle: message.ReceiptHandle!,
          }));
        } catch (err) {
          console.error(`Failed (attempt ${receiveCount}):`, err);
          // Don't delete — message will reappear after VisibilityTimeout
          // After maxReceiveCount, SQS moves it to DLQ automatically
        }
      })
    );
  }
}

---

SNS → SQS Fan-Out Pattern

One SNS topic, multiple SQS queues. Each queue serves a different consumer:

# terraform/messaging.tf

# SNS Topic (the event bus)
resource "aws_sns_topic" "orders" {
  name = "${var.name}-${var.environment}-orders"

  # For FIFO:
  # name              = "${var.name}-${var.environment}-orders.fifo"
  # fifo_topic        = true
  # content_based_deduplication = true

  tags = var.common_tags
}

# SQS Queue: fulfillment service
resource "aws_sqs_queue" "fulfillment" {
  name                      = "${var.name}-${var.environment}-fulfillment"
  visibility_timeout_seconds = 60
  message_retention_seconds  = 86400   # 1 day
  receive_wait_time_seconds  = 20      # Long polling

  redrive_policy = jsonencode({
    deadLetterTargetArn = aws_sqs_queue.fulfillment_dlq.arn
    maxReceiveCount     = 3            # Move to DLQ after 3 failures
  })

  tags = var.common_tags
}

resource "aws_sqs_queue" "fulfillment_dlq" {
  name                      = "${var.name}-${var.environment}-fulfillment-dlq"
  message_retention_seconds = 1209600  # 14 days

  tags = var.common_tags
}

# SQS Queue: notification service
resource "aws_sqs_queue" "notifications" {
  name                       = "${var.name}-${var.environment}-notifications"
  visibility_timeout_seconds = 30
  message_retention_seconds  = 3600    # 1 hour (notifications expire quickly)
  receive_wait_time_seconds  = 20

  redrive_policy = jsonencode({
    deadLetterTargetArn = aws_sqs_queue.notifications_dlq.arn
    maxReceiveCount     = 2
  })

  tags = var.common_tags
}

resource "aws_sqs_queue" "notifications_dlq" {
  name = "${var.name}-${var.environment}-notifications-dlq"
  tags = var.common_tags
}

# SQS Queue: analytics service (only certain events)
resource "aws_sqs_queue" "analytics" {
  name                       = "${var.name}-${var.environment}-analytics"
  visibility_timeout_seconds = 120     # Analytics jobs take longer
  message_retention_seconds  = 604800  # 7 days

  redrive_policy = jsonencode({
    deadLetterTargetArn = aws_sqs_queue.analytics_dlq.arn
    maxReceiveCount     = 5
  })

  tags = var.common_tags
}

resource "aws_sqs_queue" "analytics_dlq" {
  name = "${var.name}-${var.environment}-analytics-dlq"
  tags = var.common_tags
}

# Allow SNS to publish to each SQS queue
resource "aws_sqs_queue_policy" "fulfillment" {
  queue_url = aws_sqs_queue.fulfillment.id
  policy = jsonencode({
    Version = "2012-10-17"
    Statement = [{
      Effect    = "Allow"
      Principal = { Service = "sns.amazonaws.com" }
      Action    = "sqs:SendMessage"
      Resource  = aws_sqs_queue.fulfillment.arn
      Condition = {
        ArnEquals = { "aws:SourceArn" = aws_sns_topic.orders.arn }
      }
    }]
  })
}

# SNS → SQS subscriptions with message filtering
resource "aws_sns_topic_subscription" "fulfillment" {
  topic_arn = aws_sns_topic.orders.arn
  protocol  = "sqs"
  endpoint  = aws_sqs_queue.fulfillment.arn

  # Filter policy: only receive order.created and order.updated events
  filter_policy = jsonencode({
    eventType = ["order.created", "order.updated", "order.cancelled"]
  })

  # Deliver message as raw (not wrapped in SNS envelope)
  raw_message_delivery = true
}

resource "aws_sns_topic_subscription" "notifications" {
  topic_arn = aws_sns_topic.orders.arn
  protocol  = "sqs"
  endpoint  = aws_sqs_queue.notifications.arn

  # Notifications need all order events
  filter_policy = jsonencode({
    eventType = ["order.created", "order.shipped", "order.delivered", "order.cancelled"]
  })

  raw_message_delivery = true
}

resource "aws_sns_topic_subscription" "analytics" {
  topic_arn = aws_sns_topic.orders.arn
  protocol  = "sqs"
  endpoint  = aws_sqs_queue.analytics.arn

  # Analytics gets EVERYTHING (no filter)
  raw_message_delivery = true
}

---

SNS Message Filtering with Attributes

// lib/aws/sns-publisher.ts
import { SNSClient, PublishCommand } from "@aws-sdk/client-sns";

const sns = new SNSClient({ region: process.env.AWS_REGION });

interface OrderEvent {
  eventType: "order.created" | "order.updated" | "order.shipped" | "order.cancelled" | "order.delivered";
  orderId: string;
  customerId: string;
  total: number;
  priority?: "standard" | "express";
}

export async function publishOrderEvent(event: OrderEvent) {
  await sns.send(new PublishCommand({
    TopicArn: process.env.SNS_ORDERS_TOPIC_ARN!,
    Message: JSON.stringify(event),
    Subject: event.eventType,
    // Message attributes control filter policy routing
    MessageAttributes: {
      eventType: {
        DataType: "String",
        StringValue: event.eventType,
      },
      priority: {
        DataType: "String",
        StringValue: event.priority ?? "standard",
      },
      totalRange: {
        DataType: "Number",
        StringValue: String(event.total),
      },
    },
  }));
}

---

FIFO Queues for Ordered Processing

Use FIFO when order matters — e.g., account state machines, inventory adjustments:

// lib/aws/fifo-queue.ts
import { SQSClient, SendMessageCommand } from "@aws-sdk/client-sqs";
import { createHash } from "crypto";

const sqs = new SQSClient({ region: process.env.AWS_REGION });

export async function enqueueOrderedEvent({
  queueUrl,
  groupId,          // All messages with same groupId are processed in order
  payload,
  deduplicationId,  // Prevents duplicates within 5-minute window
}: {
  queueUrl: string;
  groupId: string;
  payload: object;
  deduplicationId?: string;
}) {
  const body = JSON.stringify(payload);
  const dedupId = deduplicationId ??
    createHash("sha256").update(body).digest("hex"); // Content-based dedup

  await sqs.send(new SendMessageCommand({
    QueueUrl: queueUrl,          // Must end in .fifo
    MessageBody: body,
    MessageGroupId: groupId,     // e.g., customerId, accountId, orderId
    MessageDeduplicationId: dedupId,
  }));
}

// Example: process subscription state machine in order per customer
await enqueueOrderedEvent({
  queueUrl: process.env.SUBSCRIPTION_FIFO_QUEUE_URL!,
  groupId: `customer-${customerId}`,   // One group per customer
  payload: { event: "subscription.upgraded", customerId, newPlan: "pro" },
  deduplicationId: `upgrade-${subscriptionId}-${Date.now()}`,
});

---

Lambda Trigger with Batch Processing

# Lambda triggered by SQS (fulfillment queue)
resource "aws_lambda_event_source_mapping" "fulfillment" {
  event_source_arn = aws_sqs_queue.fulfillment.arn
  function_name    = aws_lambda_function.fulfillment.arn

  batch_size                         = 10    # Process up to 10 messages at once
  maximum_batching_window_in_seconds = 5     # Wait up to 5s to fill batch

  # Partial batch failure reporting — only delete successfully processed messages
  function_response_types = ["ReportBatchItemFailures"]

  # Concurrency: max 5 concurrent Lambda invocations for this queue
  scaling_config {
    maximum_concurrency = 5
  }
}

// handlers/fulfillment.ts — Lambda handler with partial batch failure
import type { SQSEvent, SQSBatchResponse } from "aws-lambda";

export async function handler(event: SQSEvent): Promise<SQSBatchResponse> {
  const failures: string[] = [];

  await Promise.allSettled(
    event.Records.map(async (record) => {
      try {
        const body = JSON.parse(record.body);
        await processFulfillmentEvent(body);
      } catch (err) {
        console.error(`Failed to process message ${record.messageId}:`, err);
        // Report this message as failed — SQS will NOT delete it
        // (after maxReceiveCount, it goes to DLQ)
        failures.push(record.messageId);
      }
    })
  );

  return {
    batchItemFailures: failures.map((id) => ({ itemIdentifier: id })),
  };
}

async function processFulfillmentEvent(body: {
  eventType: string;
  orderId: string;
}) {
  switch (body.eventType) {
    case "order.created":
      await reserveInventory(body.orderId);
      await scheduleShipment(body.orderId);
      break;
    case "order.cancelled":
      await releaseInventory(body.orderId);
      break;
  }
}

---

DLQ Alarm + Reprocessing

# Alert when DLQ has messages
resource "aws_cloudwatch_metric_alarm" "fulfillment_dlq" {
  alarm_name          = "${var.name}-fulfillment-dlq-depth"
  comparison_operator = "GreaterThanThreshold"
  evaluation_periods  = 1
  metric_name         = "ApproximateNumberOfMessagesVisible"
  namespace           = "AWS/SQS"
  period              = 60
  statistic           = "Sum"
  threshold           = 0       # Alert on ANY DLQ message
  alarm_description   = "Fulfillment DLQ has failed messages"
  alarm_actions       = [aws_sns_topic.alerts.arn]

  dimensions = {
    QueueName = aws_sqs_queue.fulfillment_dlq.name
  }
}

// scripts/redrive-dlq.ts — Reprocess DLQ messages after fixing the bug
import {
  SQSClient,
  StartMessageMoveTaskCommand,
  ListMessageMoveTasksCommand,
} from "@aws-sdk/client-sqs";

const sqs = new SQSClient({ region: process.env.AWS_REGION! });

async function redriveFromDLQ(dlqArn: string, targetQueueArn: string) {
  // Start redrive task (built-in SQS feature — no need to write code)
  const task = await sqs.send(new StartMessageMoveTaskCommand({
    SourceArn: dlqArn,
    DestinationArn: targetQueueArn,
    MaxNumberOfMessagesPerSecond: 100, // Throttle to avoid overwhelming consumer
  }));

  console.log("Redrive task started:", task.TaskHandle);

  // Monitor progress
  while (true) {
    const tasks = await sqs.send(new ListMessageMoveTasksCommand({
      SourceArn: dlqArn,
    }));
    const current = tasks.Results?.find((t) => t.TaskHandle === task.TaskHandle);

    if (!current) break;
    console.log(`Moved: ${current.ApproximateNumberOfMessagesMoved} / ${current.ApproximateNumberOfMessagesToMove}`);

    if (current.Status === "COMPLETED" || current.Status === "FAILED") break;
    await new Promise((r) => setTimeout(r, 5000));
  }
}

---

Cost Comparison

SQS/SNS is extremely cheap — messaging is rarely the cost driver. Lambda execution and DLQ alarm management are more relevant cost considerations.

---

See Also

• AWS SQS Dead Letter Queue — DLQ configuration and monitoring
• AWS EventBridge — Event routing alternative to SNS
• AWS Lambda Layers — Shared code for Lambda consumers
• Kubernetes Cost Optimization — When to choose K8s consumers over Lambda

---

Working With Viprasol

We design and implement SQS/SNS messaging architectures for event-driven SaaS products — from simple single-queue setups through multi-service fan-out with FIFO ordering and DLQ monitoring. Our cloud team has shipped messaging systems processing millions of events per day with zero message loss.

What we deliver:

• SNS fan-out architecture design (topics, subscriptions, filter policies)
• FIFO queue setup for ordered processing requirements
• Lambda event source mapping with partial batch failure
• DLQ CloudWatch alarms and one-click redrive automation
• Terraform module for the full messaging stack

See our cloud infrastructure services or contact us to design your messaging architecture.
