Stripe Connect for Marketplaces: Split Payments, Onboarding, and Payouts

Marketplaces — platforms where buyers pay sellers through your product — have non-trivial payment infrastructure requirements. You need to collect money from buyers, split it between sellers and yourself, handle failed payouts, manage compliance across jurisdictions, and onboard sellers without requiring them to have existing payment accounts.

Stripe Connect is the most complete managed solution for this. This guide covers the complete implementation: account types, onboarding flows, payment splitting, webhook handling, and the failure cases most tutorials skip.

---

Stripe Connect Account Types

Three account types exist, each with different tradeoffs:

Recommendation for most marketplaces: Express. You get Stripe-hosted KYC/KYB onboarding (they handle identity verification, bank account collection, and compliance), your platform brand is visible, and sellers use a simplified Stripe Express dashboard rather than the full Stripe interface.

---

Step 1: Create a Connected Account and Onboarding Link

// lib/stripe.ts
import Stripe from 'stripe';

const stripe = new Stripe(process.env.STRIPE_SECRET_KEY!, {
  apiVersion: '2024-12-18',
  typescript: true,
});

export { stripe };

// api/sellers/onboard.ts — Create Express account + onboarding link
export async function POST(request: Request) {
  const { sellerId, email, businessType } = await request.json();

  // 1. Check if seller already has a Stripe account
  const seller = await db.seller.findUnique({ where: { id: sellerId } });

  let stripeAccountId = seller?.stripeAccountId;

  if (!stripeAccountId) {
    // 2. Create Express connected account
    const account = await stripe.accounts.create({
      type: 'express',
      email,
      business_type: businessType ?? 'individual', // 'individual' | 'company'
      capabilities: {
        card_payments: { requested: true },
        transfers: { requested: true },
      },
      settings: {
        payouts: {
          schedule: {
            interval: 'weekly',  // 'daily' | 'weekly' | 'monthly'
            weekly_anchor: 'monday',
          },
        },
      },
      metadata: { sellerId },
    });

    stripeAccountId = account.id;

    // 3. Save to DB
    await db.seller.update({
      where: { id: sellerId },
      data: {
        stripeAccountId,
        stripeOnboardingStatus: 'pending',
      },
    });
  }

  // 4. Generate onboarding link (expires after ~1 hour)
  const accountLink = await stripe.accountLinks.create({
    account: stripeAccountId,
    refresh_url: `${process.env.APP_URL}/sellers/onboard/refresh`,
    return_url: `${process.env.APP_URL}/sellers/onboard/complete`,
    type: 'account_onboarding',
  });

  return Response.json({ url: accountLink.url });
}

The seller clicks the link, completes Stripe's hosted flow (identity, bank account), and lands on your return_url. Check their account status there:

// api/sellers/onboard/complete.ts
export async function GET(request: Request) {
  const { searchParams } = new URL(request.url);
  const sellerId = searchParams.get('sellerId')!;

  const seller = await db.seller.findUnique({ where: { id: sellerId } });
  const account = await stripe.accounts.retrieve(seller!.stripeAccountId!);

  const isEnabled =
    account.charges_enabled &&
    account.payouts_enabled &&
    account.details_submitted;

  await db.seller.update({
    where: { id: sellerId },
    data: {
      stripeOnboardingStatus: isEnabled ? 'complete' : 'pending',
      stripeChargesEnabled: account.charges_enabled,
      stripePayoutsEnabled: account.payouts_enabled,
    },
  });

  return Response.redirect(
    isEnabled
      ? `${process.env.APP_URL}/sellers/dashboard`
      : `${process.env.APP_URL}/sellers/onboard/incomplete`
  );
}

---

Step 2: Collecting Payment with Automatic Split

When a buyer pays, create a PaymentIntent that automatically routes the seller's share to their account:

// api/orders/create.ts
interface CreateOrderBody {
  buyerId: string;
  sellerId: string;
  items: Array<{ productId: string; quantity: number; unitPrice: number }>;
}

export async function POST(request: Request) {
  const body: CreateOrderBody = await request.json();

  const seller = await db.seller.findUnique({ where: { id: body.sellerId } });

  if (!seller?.stripeAccountId || !seller.stripeChargesEnabled) {
    return Response.json({ error: 'Seller not ready to accept payments' }, { status: 400 });
  }

  // Calculate amounts (in cents)
  const subtotalCents = body.items.reduce(
    (sum, item) => sum + item.unitPrice * item.quantity,
    0
  );
  const platformFeeCents = Math.round(subtotalCents * 0.05); // 5% platform fee
  const sellerShareCents = subtotalCents - platformFeeCents;

  // Create order record
  const order = await db.order.create({
    data: {
      buyerId: body.buyerId,
      sellerId: body.sellerId,
      subtotalCents,
      platformFeeCents,
      sellerShareCents,
      status: 'PENDING_PAYMENT',
      items: { create: body.items },
    },
  });

  // Create PaymentIntent with destination charge
  const paymentIntent = await stripe.paymentIntents.create({
    amount: subtotalCents,
    currency: 'usd',
    payment_method_types: ['card'],
    application_fee_amount: platformFeeCents,  // Platform keeps this
    transfer_data: {
      destination: seller.stripeAccountId,     // Seller receives the rest
    },
    metadata: {
      orderId: order.id,
      buyerId: body.buyerId,
      sellerId: body.sellerId,
    },
    description: `Order ${order.id} — ${body.items.length} item(s)`,
  });

  // Save PaymentIntent ID
  await db.order.update({
    where: { id: order.id },
    data: { stripePaymentIntentId: paymentIntent.id },
  });

  return Response.json({
    clientSecret: paymentIntent.client_secret,
    orderId: order.id,
  });
}

---

Step 3: Handling Webhooks

Webhooks are how Stripe tells you when payments succeed, fail, or sellers update their accounts.

// api/webhooks/stripe.ts
import { stripe } from '@/lib/stripe';

export async function POST(request: Request) {
  const rawBody = await request.arrayBuffer();
  const sig = request.headers.get('stripe-signature')!;

  let event: Stripe.Event;
  try {
    event = stripe.webhooks.constructEvent(
      Buffer.from(rawBody),
      sig,
      process.env.STRIPE_WEBHOOK_SECRET!
    );
  } catch (err) {
    console.error('Webhook signature verification failed:', err);
    return Response.json({ error: 'Invalid signature' }, { status: 400 });
  }

  // Idempotency — skip if already processed
  const existing = await db.processedStripeEvent.findUnique({
    where: { stripeEventId: event.id },
  });
  if (existing) return Response.json({ received: true });

  await db.processedStripeEvent.create({
    data: { stripeEventId: event.id, type: event.type },
  });

  switch (event.type) {
    case 'payment_intent.succeeded': {
      const pi = event.data.object as Stripe.PaymentIntent;
      await db.order.update({
        where: { stripePaymentIntentId: pi.id },
        data: { status: 'PAID', paidAt: new Date() },
      });
      await notifySellerOfNewOrder(pi.metadata.orderId);
      break;
    }

    case 'payment_intent.payment_failed': {
      const pi = event.data.object as Stripe.PaymentIntent;
      await db.order.update({
        where: { stripePaymentIntentId: pi.id },
        data: {
          status: 'PAYMENT_FAILED',
          failureReason: pi.last_payment_error?.message,
        },
      });
      break;
    }

    case 'account.updated': {
      // Seller updated their Stripe account (completed onboarding, added bank, etc.)
      const account = event.data.object as Stripe.Account;
      const seller = await db.seller.findFirst({
        where: { stripeAccountId: account.id },
      });
      if (seller) {
        await db.seller.update({
          where: { id: seller.id },
          data: {
            stripeChargesEnabled: account.charges_enabled,
            stripePayoutsEnabled: account.payouts_enabled,
            stripeOnboardingStatus:
              account.charges_enabled && account.payouts_enabled
                ? 'complete'
                : 'pending',
          },
        });
      }
      break;
    }

    case 'payout.paid': {
      const payout = event.data.object as Stripe.Payout;
      // Log successful payout to seller's bank
      await db.sellerPayout.updateMany({
        where: { stripePayoutId: payout.id },
        data: { status: 'PAID', paidAt: new Date() },
      });
      break;
    }

    case 'payout.failed': {
      const payout = event.data.object as Stripe.Payout;
      await handleFailedPayout(payout);  // Alert seller, update status
      break;
    }
  }

  return Response.json({ received: true });
}

---

Step 4: Handling Refunds

Refunds on marketplace payments require coordination between platform fee reversal and seller balance:

// api/orders/refund.ts
export async function POST(request: Request) {
  const { orderId, reason } = await request.json();

  const order = await db.order.findUnique({
    where: { id: orderId },
    include: { seller: true },
  });

  if (!order?.stripePaymentIntentId) {
    return Response.json({ error: 'Order not found or not paid' }, { status: 400 });
  }

  // Full refund — reverses both platform fee and seller transfer
  const refund = await stripe.refunds.create({
    payment_intent: order.stripePaymentIntentId,
    reason: reason ?? 'requested_by_customer',
    refund_application_fee: true,  // Refund the platform fee too
    reverse_transfer: true,         // Pull back money from seller's balance
  });

  await db.order.update({
    where: { id: orderId },
    data: {
      status: 'REFUNDED',
      stripeRefundId: refund.id,
      refundedAt: new Date(),
    },
  });

  return Response.json({ refundId: refund.id, status: refund.status });
}

---

Compliance and Risk Considerations

---

Platform Fee Strategies

---

Cost Model

Platform economics example (5% platform fee, $100 order):

• Buyer pays: $100.00
• Stripe fee: $3.20 (2.9% + $0.30)
• Platform fee: $5.00
• Stripe Connect fee: $0.25
• Net to platform: $1.55
• Net to seller: $91.25

---

Build vs Buy

For 99% of marketplaces, Stripe Connect Express is the right choice.

---
