PostgreSQL Logical Replication in 2026: CDC, Replication Slots, and Streaming to Data Warehouse

Logical replication turns PostgreSQL into an event stream. Every INSERT, UPDATE, and DELETE on replicated tables is captured and forwarded — to a replica, a data warehouse, a search index, or a cache invalidation system. Change Data Capture (CDC) is the basis for keeping analytics in sync with production without expensive full-table ETL jobs.

This post covers PostgreSQL logical replication internals, replication slots and publications, Debezium for managed CDC, streaming to Redshift/BigQuery via Kafka, the dangerous slot lag problem, and monitoring.

---

Logical vs Physical Replication

---

PostgreSQL Configuration

-- postgresql.conf changes required (restart needed):
-- wal_level = logical          (default is 'replica' — must change to 'logical')
-- max_replication_slots = 10   (default 10 — increase for multiple consumers)
-- max_wal_senders = 10         (default 10 — connections for logical replication)

-- Check current settings:
SHOW wal_level;               -- Should show 'logical'
SHOW max_replication_slots;
SHOW max_wal_senders;

-- On AWS RDS/Aurora: set via parameter group
-- rds.logical_replication = 1  (requires reboot)

---

Publications: What to Replicate

-- Publish all tables in the current database
CREATE PUBLICATION all_tables FOR ALL TABLES;

-- Publish specific tables
CREATE PUBLICATION app_events FOR TABLE
  orders,
  order_items,
  customers,
  subscriptions;

-- Publish with row filter (PostgreSQL 15+): only publish active subscriptions
CREATE PUBLICATION active_subscriptions
  FOR TABLE subscriptions (id, customer_id, plan, status, updated_at)
  WHERE (status != 'cancelled');

-- Publish only specific columns (column list filtering, PostgreSQL 15+)
CREATE PUBLICATION customers_public
  FOR TABLE customers (id, email, name, created_at)
  -- Excludes: phone, address, payment_method, notes
;

-- List publications
SELECT pubname, puballtables, pubinsert, pubupdate, pubdelete
FROM pg_publication;

---

Replication Slots

-- Create a logical replication slot (for direct subscription)
SELECT pg_create_logical_replication_slot(
  'my_consumer',           -- Slot name (must be unique)
  'pgoutput'               -- Output plugin ('pgoutput' = standard, 'wal2json' = JSON)
);

-- List all slots and their lag
SELECT
  slot_name,
  plugin,
  active,
  active_pid,
  confirmed_flush_lsn,
  pg_current_wal_lsn() - confirmed_flush_lsn AS lag_bytes,
  pg_size_pretty(pg_current_wal_lsn() - confirmed_flush_lsn) AS lag_pretty
FROM pg_replication_slots;

-- ⚠️ CRITICAL: unused slots accumulate WAL indefinitely (can fill disk!)
-- Always monitor slot lag and drop unused slots immediately
SELECT pg_drop_replication_slot('my_consumer');

---

Native Subscription (PostgreSQL → PostgreSQL)

-- On the SUBSCRIBER (replica) database:

CREATE SUBSCRIPTION my_sub
  CONNECTION 'host=primary-db.example.com port=5432 dbname=myapp user=replication password=...'
  PUBLICATION app_events
  WITH (
    copy_data = true,          -- Copy initial snapshot
    connect = true,
    enabled = true,
    slot_name = 'my_sub_slot', -- Auto-created on publisher
    synchronous_commit = off   -- Don't wait for subscriber confirmation
  );

-- Monitor subscription status
SELECT subname, subenabled, subslotname, subpublications
FROM pg_subscription;

-- Check replication lag on subscriber
SELECT
  application_name,
  state,
  sent_lsn,
  write_lsn,
  flush_lsn,
  replay_lsn,
  (sent_lsn - replay_lsn) AS lag_bytes
FROM pg_stat_replication;

---

Debezium: CDC to Kafka

Debezium is the standard for PostgreSQL CDC. It reads the WAL via a replication slot and publishes change events to Kafka topics:

# debezium/postgres-connector.json
{
  "name": "postgres-connector",
  "config": {
    "connector.class": "io.debezium.connector.postgresql.PostgresConnector",
    "tasks.max": "1",

    "database.hostname": "primary-db.example.com",
    "database.port": "5432",
    "database.user": "debezium",
    "database.password": "${file:/secrets.properties:db.password}",
    "database.dbname": "myapp",
    "database.server.name": "myapp",

    "plugin.name": "pgoutput",
    "slot.name": "debezium_slot",
    "publication.name": "app_events",

    "table.include.list": "public.orders,public.customers,public.subscriptions",

    "heartbeat.interval.ms": "10000",
    "heartbeat.action.query": "INSERT INTO debezium_heartbeat (id) VALUES (1) ON CONFLICT (id) DO UPDATE SET updated_at = now()",

    "transforms": "unwrap",
    "transforms.unwrap.type": "io.debezium.transforms.ExtractNewRecordState",
    "transforms.unwrap.drop.tombstones": "false",
    "transforms.unwrap.delete.handling.mode": "rewrite",
    "transforms.unwrap.add.fields": "op,source.ts_ms",

    "snapshot.mode": "initial",
    "decimal.handling.mode": "double",
    "time.precision.mode": "connect"
  }
}

-- Required: replication user with permissions
CREATE USER debezium WITH REPLICATION PASSWORD 'strong-password';
GRANT SELECT ON ALL TABLES IN SCHEMA public TO debezium;

-- Heartbeat table (prevents slot lag during quiet periods)
CREATE TABLE debezium_heartbeat (
  id         INTEGER PRIMARY KEY DEFAULT 1,
  updated_at TIMESTAMPTZ DEFAULT now()
);
GRANT INSERT, UPDATE ON debezium_heartbeat TO debezium;

---

Kafka → Data Warehouse (Custom Consumer)

// consumers/warehouse-sink.ts
// Consumes Debezium CDC events from Kafka, sinks to Redshift/BigQuery

import { Kafka } from "kafkajs";
import { Pool } from "pg"; // Redshift is PostgreSQL-compatible

const kafka = new Kafka({
  clientId: "warehouse-sink",
  brokers: process.env.KAFKA_BROKERS!.split(","),
  ssl: true,
  sasl: { mechanism: "scram-sha-256", username: process.env.KAFKA_USER!, password: process.env.KAFKA_PASS! },
});

const redshift = new Pool({ connectionString: process.env.REDSHIFT_URL });

const consumer = kafka.consumer({ groupId: "warehouse-sink-group" });

async function processChangeEvent(event: {
  op: "c" | "u" | "d" | "r";  // create, update, delete, read (snapshot)
  id: string;
  [key: string]: unknown;
}) {
  switch (event.op) {
    case "c":
    case "r":  // Snapshot read = same as create
      await redshift.query(
        `INSERT INTO orders_dw (id, customer_id, total, status, created_at, synced_at)
         VALUES ($1, $2, $3, $4, $5, now())
         ON CONFLICT (id) DO UPDATE SET
           customer_id = EXCLUDED.customer_id,
           total       = EXCLUDED.total,
           status      = EXCLUDED.status,
           synced_at   = now()`,
        [event.id, event.customer_id, event.total, event.status, event.created_at]
      );
      break;

    case "u":
      await redshift.query(
        `UPDATE orders_dw SET
           total     = $2,
           status    = $3,
           synced_at = now()
         WHERE id = $1`,
        [event.id, event.total, event.status]
      );
      break;

    case "d":
      await redshift.query(
        `UPDATE orders_dw SET deleted_at = now() WHERE id = $1`,
        [event.id]
      );
      break;
  }
}

async function run() {
  await consumer.connect();
  await consumer.subscribe({ topics: ["myapp.public.orders"], fromBeginning: false });

  await consumer.run({
    eachBatchAutoResolve: true,
    eachBatch: async ({ batch, resolveOffset, heartbeat }) => {
      for (const message of batch.messages) {
        const event = JSON.parse(message.value!.toString());
        await processChangeEvent(event);
        resolveOffset(message.offset);
        await heartbeat();
      }
    },
  });
}

run().catch(console.error);

---

Slot Lag Monitoring (Critical)

-- Monitor slot lag — alert if above threshold (e.g., 1GB)
SELECT
  slot_name,
  active,
  pg_size_pretty(pg_current_wal_lsn() - confirmed_flush_lsn) AS lag,
  (pg_current_wal_lsn() - confirmed_flush_lsn) AS lag_bytes
FROM pg_replication_slots
ORDER BY lag_bytes DESC NULLS LAST;

-- Alert query for monitoring (CloudWatch custom metric or Prometheus):
-- Trigger alarm if lag_bytes > 1073741824 (1GB)

// lib/monitoring/slot-lag.ts
// Run every 5 minutes via EventBridge cron

import { db } from "@/lib/db";
import { CloudWatchClient, PutMetricDataCommand } from "@aws-sdk/client-cloudwatch";

const cw = new CloudWatchClient({ region: process.env.AWS_REGION });

export async function reportSlotLag() {
  const slots = await db.$queryRaw<{
    slot_name: string;
    lag_bytes: bigint;
    active: boolean;
  }[]>`
    SELECT
      slot_name,
      pg_current_wal_lsn() - confirmed_flush_lsn AS lag_bytes,
      active
    FROM pg_replication_slots
  `;

  await cw.send(new PutMetricDataCommand({
    Namespace: "MyApp/Database",
    MetricData: slots.map((slot) => ({
      MetricName: "ReplicationSlotLagBytes",
      Dimensions: [{ Name: "SlotName", Value: slot.slot_name }],
      Value: Number(slot.lag_bytes ?? 0),
      Unit: "Bytes",
    })),
  }));
}

---
