AWS RDS Read Replicas: Routing, Connection Pooling, Lag Monitoring, and Failover Patterns

Read replicas offload SELECT queries from your primary RDS instance, letting it focus on writes. The performance improvement is significant: if 80% of your queries are reads, a single replica can cut primary load in half. The implementation challenge is routing — making sure writes always go to the primary, reads go to replicas, and your application handles the replica lag gracefully.

When Read Replicas Help (and When They Don't)

Terraform: RDS with Read Replicas

# terraform/rds-replicas.tf

# Primary instance
resource "aws_db_instance" "primary" {
  identifier           = "${var.app_name}-primary"
  engine               = "postgres"
  engine_version       = "16.3"
  instance_class       = "db.t4g.large"
  allocated_storage    = 100
  storage_type         = "gp3"
  storage_encrypted    = true

  db_name  = var.db_name
  username = var.db_username
  password = var.db_password

  db_subnet_group_name   = aws_db_subnet_group.main.name
  vpc_security_group_ids = [aws_security_group.rds.id]
  multi_az               = true   # Synchronous standby for failover

  # Enable enhanced monitoring for replica lag metrics
  monitoring_interval = 60
  monitoring_role_arn = aws_iam_role.rds_monitoring.arn

  # Backup for Point-in-Time Recovery
  backup_retention_period = 7
  backup_window           = "03:00-04:00"
  maintenance_window      = "sun:04:30-sun:05:30"

  # Required for read replicas
  parameter_group_name = aws_db_parameter_group.postgres16.name

  tags = local.tags
}

# Read replica 1 (same region, different AZ)
resource "aws_db_instance" "replica_1" {
  identifier             = "${var.app_name}-replica-1"
  replicate_source_db    = aws_db_instance.primary.identifier
  instance_class         = "db.t4g.medium"  # Can be smaller than primary
  publicly_accessible    = false
  vpc_security_group_ids = [aws_security_group.rds.id]

  # Replicas don't need backups (primary has them)
  backup_retention_period = 0
  skip_final_snapshot     = true

  # Auto-minor version upgrade
  auto_minor_version_upgrade = true

  tags = merge(local.tags, { Role = "replica" })
}

# Optional: replica in a different region (cross-region)
# resource "aws_db_instance" "replica_eu" {
#   provider              = aws.eu_west_1
#   replicate_source_db   = aws_db_instance.primary.arn  # ARN for cross-region
#   ...
# }

# CloudWatch alarm: replica lag > 30 seconds
resource "aws_cloudwatch_metric_alarm" "replica_lag" {
  alarm_name          = "${var.app_name}-replica-lag"
  comparison_operator = "GreaterThanThreshold"
  evaluation_periods  = 2
  metric_name         = "ReplicaLag"
  namespace           = "AWS/RDS"
  period              = 60
  statistic           = "Average"
  threshold           = 30    # seconds
  alarm_actions       = [var.sns_alert_topic_arn]

  dimensions = {
    DBInstanceIdentifier = aws_db_instance.replica_1.identifier
  }
}

output "primary_endpoint" {
  value = aws_db_instance.primary.endpoint
}

output "replica_endpoint" {
  value = aws_db_instance.replica_1.endpoint
}

Prisma: Read/Write Splitting

// lib/prisma.ts — separate clients for primary and replica

import { PrismaClient } from "@prisma/client";

function createPrismaClient(databaseUrl: string) {
  return new PrismaClient({
    datasources: { db: { url: databaseUrl } },
    log: process.env.NODE_ENV === "development" ? ["query", "error"] : ["error"],
  });
}

// Primary: all writes + reads requiring freshness
const primaryClient = createPrismaClient(process.env.DATABASE_URL!);

// Replica: read-only queries
const replicaClient = process.env.DATABASE_REPLICA_URL
  ? createPrismaClient(process.env.DATABASE_REPLICA_URL)
  : primaryClient;  // Fallback to primary if no replica configured

export const prisma   = primaryClient;
export const prismaRO = replicaClient;   // "RO" = read-only

// Usage pattern:
// import { prisma, prismaRO } from "@/lib/prisma";
// const user = await prismaRO.user.findUnique(...)   ← reads from replica
// await prisma.user.update(...)                       ← writes to primary

Read/Write Routing Layer

// lib/db/router.ts — route queries based on operation type

import { prisma, prismaRO } from "@/lib/prisma";
import type { Prisma } from "@prisma/client";

// Read operations that can use replica (stale data acceptable)
export async function readFromReplica<T>(
  query: (client: typeof prismaRO) => Promise<T>
): Promise<T> {
  return query(prismaRO);
}

// Write + read: always use primary
export async function readFromPrimary<T>(
  query: (client: typeof prisma) => Promise<T>
): Promise<T> {
  return query(prisma);
}

// Practical usage:
// Reports, dashboards, list pages → replica
// Post-write reads ("read your writes") → primary

// Example: dashboard stats (stale ok, use replica)
export async function getDashboardStats(workspaceId: string) {
  return readFromReplica((db) =>
    db.project.groupBy({
      by:     ["status"],
      where:  { workspaceId },
      _count: { id: true },
    })
  );
}

// Example: fetch user after updating (must use primary)
export async function updateAndFetchUser(userId: string, data: Prisma.UserUpdateInput) {
  const updated = await prisma.user.update({ where: { id: userId }, data });
  // Read from PRIMARY — replica may be 100-200ms behind
  const fresh = await readFromPrimary((db) =>
    db.user.findUniqueOrThrow({ where: { id: userId } })
  );
  return fresh;
}

Monitoring Replica Lag

// lib/monitoring/replica-lag.ts
import { CloudWatchClient, GetMetricStatisticsCommand } from "@aws-sdk/client-cloudwatch";

const cw = new CloudWatchClient({ region: process.env.AWS_REGION });

export async function getReplicaLagSeconds(): Promise<number> {
  const now  = new Date();
  const past = new Date(now.getTime() - 5 * 60 * 1000); // Last 5 minutes

  const result = await cw.send(
    new GetMetricStatisticsCommand({
      Namespace:  "AWS/RDS",
      MetricName: "ReplicaLag",
      Dimensions: [
        { Name: "DBInstanceIdentifier", Value: process.env.RDS_REPLICA_ID! },
      ],
      StartTime:  past,
      EndTime:    now,
      Period:     60,
      Statistics: ["Average"],
    })
  );

  const points = result.Datapoints ?? [];
  if (points.length === 0) return 0;

  return Math.max(...points.map((p) => p.Average ?? 0));
}

// Health check: skip replica if lagging > 5 seconds
export async function getReadClient() {
  const lagSeconds = await getReplicaLagSeconds();
  if (lagSeconds > 5) {
    console.warn(`[replica] Lag ${lagSeconds}s > 5s — routing to primary`);
    return prisma;   // Fall back to primary
  }
  return prismaRO;
}

Aurora: Automatic Failover and Cluster Endpoint

# For Aurora PostgreSQL: use cluster endpoint — auto-routes to current writer
resource "aws_rds_cluster" "aurora" {
  cluster_identifier   = "${var.app_name}-aurora"
  engine               = "aurora-postgresql"
  engine_version       = "16.3"
  database_name        = var.db_name
  master_username      = var.db_username
  master_password      = var.db_password
  storage_encrypted    = true

  db_subnet_group_name   = aws_db_subnet_group.main.name
  vpc_security_group_ids = [aws_security_group.rds.id]

  backup_retention_period = 7
  preferred_backup_window = "03:00-04:00"

  skip_final_snapshot = false
  final_snapshot_identifier = "${var.app_name}-final"
}

# Writer instance
resource "aws_rds_cluster_instance" "writer" {
  identifier         = "${var.app_name}-writer"
  cluster_identifier = aws_rds_cluster.aurora.id
  instance_class     = "db.t4g.large"
  engine             = aws_rds_cluster.aurora.engine
}

# Reader instance (Aurora auto-promotes to writer on failover)
resource "aws_rds_cluster_instance" "reader" {
  identifier         = "${var.app_name}-reader"
  cluster_identifier = aws_rds_cluster.aurora.id
  instance_class     = "db.t4g.medium"
  engine             = aws_rds_cluster.aurora.engine
}

output "aurora_writer_endpoint" {
  value = aws_rds_cluster.aurora.endpoint        # Always points to current writer
}

output "aurora_reader_endpoint" {
  value = aws_rds_cluster.aurora.reader_endpoint  # Round-robins across readers
}

// Aurora endpoints in Prisma
// DATABASE_URL     = aurora_writer_endpoint (writes)
// DATABASE_REPLICA_URL = aurora_reader_endpoint (reads)
// Aurora handles failover automatically — no DNS update needed

Cost Comparison
