AWS Aurora Serverless v2: Setup, Auto-Pause, RDS Proxy, and Connection Pooling

Aurora Serverless v2 solves one of the hardest database capacity problems: unpredictable traffic. Standard RDS requires you to provision for peak — you pick an instance size and pay for it whether traffic is 1 req/s or 1,000 req/s. Aurora Serverless v2 scales in fractions of an ACU (Aurora Capacity Unit) within seconds, so you pay for what you actually use.

The tradeoff: it's more expensive per unit than standard Aurora at constant load, but significantly cheaper when traffic is variable or bursty — which describes most SaaS applications.

When Aurora Serverless v2 Makes Sense

Terraform Setup

# terraform/aurora-serverless.tf

# DB Subnet Group (subnets must span multiple AZs)
resource "aws_db_subnet_group" "aurora" {
  name       = "${var.app_name}-aurora"
  subnet_ids = var.private_subnet_ids
  tags       = var.common_tags
}

# Security Group: allow inbound from app tier
resource "aws_security_group" "aurora" {
  name   = "${var.app_name}-aurora"
  vpc_id = var.vpc_id

  ingress {
    from_port       = 5432
    to_port         = 5432
    protocol        = "tcp"
    security_groups = [aws_security_group.app.id, aws_security_group.rds_proxy.id]
  }

  egress {
    from_port   = 0
    to_port     = 0
    protocol    = "-1"
    cidr_blocks = ["0.0.0.0/0"]
  }
}

# Aurora Serverless v2 Cluster
resource "aws_rds_cluster" "app" {
  cluster_identifier      = var.app_name
  engine                  = "aurora-postgresql"
  engine_mode             = "provisioned"    # Required for Serverless v2
  engine_version          = "16.4"
  database_name           = var.db_name
  master_username         = "postgres"
  manage_master_user_password = true        # Secrets Manager manages password rotation

  db_subnet_group_name    = aws_db_subnet_group.aurora.name
  vpc_security_group_ids  = [aws_security_group.aurora.id]

  storage_encrypted       = true
  kms_key_id              = aws_kms_key.aurora.arn

  backup_retention_period = 14             # 14 days of automated backups
  preferred_backup_window = "03:00-04:00"  # UTC
  deletion_protection     = var.environment == "production"

  # Enable Data API (for Lambda without VPC, or AWS Console queries)
  enable_http_endpoint    = var.enable_data_api

  serverlessv2_scaling_configuration {
    min_capacity = var.aurora_min_acu  # 0.5 ACU minimum for dev, 2 for prod
    max_capacity = var.aurora_max_acu  # 8 for staging, 64 for production
    # Auto-pause: set seconds_until_auto_pause (dev only — pauses after N seconds idle)
    # NOT recommended for production (resume takes 15-30 seconds)
    seconds_until_auto_pause = var.environment != "production" ? 300 : null
  }

  skip_final_snapshot     = var.environment != "production"
  final_snapshot_identifier = var.environment == "production"
    ? "${var.app_name}-final-snapshot" : null

  tags = var.common_tags
}

# Writer instance (required even for Serverless v2)
resource "aws_rds_cluster_instance" "writer" {
  identifier           = "${var.app_name}-writer"
  cluster_identifier   = aws_rds_cluster.app.id
  instance_class       = "db.serverless"    # Serverless v2 class
  engine               = aws_rds_cluster.app.engine
  engine_version       = aws_rds_cluster.app.engine_version
  db_subnet_group_name = aws_db_subnet_group.aurora.name

  performance_insights_enabled          = true
  performance_insights_retention_period = 7  # days (7 free, 731 costs extra)
  monitoring_interval                   = 60 # seconds (Enhanced Monitoring)
  monitoring_role_arn                   = aws_iam_role.rds_monitoring.arn

  tags = var.common_tags
}

# Reader instance (Multi-AZ read scaling)
resource "aws_rds_cluster_instance" "reader" {
  count                = var.environment == "production" ? 1 : 0
  identifier           = "${var.app_name}-reader"
  cluster_identifier   = aws_rds_cluster.app.id
  instance_class       = "db.serverless"
  engine               = aws_rds_cluster.app.engine
  engine_version       = aws_rds_cluster.app.engine_version
  db_subnet_group_name = aws_db_subnet_group.aurora.name

  performance_insights_enabled = true
  tags                         = var.common_tags
}

# Parameter group: PostgreSQL tuning for Aurora
resource "aws_rds_cluster_parameter_group" "app" {
  name   = "${var.app_name}-pg16"
  family = "aurora-postgresql16"

  parameter {
    name  = "shared_preload_libraries"
    value = "pg_stat_statements,auto_explain"
  }
  parameter {
    name  = "log_min_duration_statement"
    value = "1000"  # Log queries >1s
  }
  parameter {
    name  = "auto_explain.log_min_duration"
    value = "5000"  # Explain queries >5s
  }
  parameter {
    name  = "log_connections"
    value = "1"
  }
}

output "cluster_endpoint"        { value = aws_rds_cluster.app.endpoint }
output "cluster_reader_endpoint" { value = aws_rds_cluster.app.reader_endpoint }
output "cluster_port"            { value = aws_rds_cluster.app.port }

RDS Proxy for Connection Pooling

Aurora Serverless v2 handles connection pooling less aggressively than standard Aurora. RDS Proxy sits between your app and Aurora, pooling connections and preventing connection storms from Lambda cold starts:

# terraform/rds-proxy.tf

resource "aws_security_group" "rds_proxy" {
  name   = "${var.app_name}-rds-proxy"
  vpc_id = var.vpc_id

  egress {
    from_port       = 5432
    to_port         = 5432
    protocol        = "tcp"
    security_groups = [aws_security_group.aurora.id]
  }

  ingress {
    from_port       = 5432
    to_port         = 5432
    protocol        = "tcp"
    security_groups = [aws_security_group.app.id]
  }
}

# IAM role for Proxy to read Secrets Manager
resource "aws_iam_role" "rds_proxy" {
  name = "${var.app_name}-rds-proxy"
  assume_role_policy = jsonencode({
    Version = "2012-10-17"
    Statement = [{
      Effect    = "Allow"
      Principal = { Service = "rds.amazonaws.com" }
      Action    = "sts:AssumeRole"
    }]
  })
}

resource "aws_iam_role_policy" "rds_proxy_secrets" {
  role = aws_iam_role.rds_proxy.id
  policy = jsonencode({
    Version = "2012-10-17"
    Statement = [{
      Effect   = "Allow"
      Action   = ["secretsmanager:GetSecretValue"]
      Resource = [aws_rds_cluster.app.master_user_secret[0].secret_arn]
    }]
  })
}

resource "aws_db_proxy" "app" {
  name                   = var.app_name
  debug_logging          = false
  engine_family          = "POSTGRESQL"
  idle_client_timeout    = 1800    # 30 min idle before proxy closes client conn
  require_tls            = true
  role_arn               = aws_iam_role.rds_proxy.arn
  vpc_security_group_ids = [aws_security_group.rds_proxy.id]
  vpc_subnet_ids         = var.private_subnet_ids

  auth {
    auth_scheme               = "SECRETS"
    secret_arn                = aws_rds_cluster.app.master_user_secret[0].secret_arn
    iam_auth                  = "DISABLED"   # Set to "REQUIRED" for IAM-only auth
  }
}

resource "aws_db_proxy_default_target_group" "app" {
  db_proxy_name = aws_db_proxy.app.name

  connection_pool_config {
    connection_borrow_timeout    = 120  # Max seconds to wait for pooled connection
    max_connections_percent      = 90   # Use 90% of Aurora's max_connections
    max_idle_connections_percent = 50   # Keep 50% of connections open when idle
  }
}

resource "aws_db_proxy_target" "app" {
  db_cluster_identifier = aws_rds_cluster.app.id
  db_proxy_name         = aws_db_proxy.app.name
  target_group_name     = aws_db_proxy_default_target_group.app.name
}

output "proxy_endpoint" { value = aws_db_proxy.app.endpoint }

Application Connection

// lib/database/connection.ts
import { Pool } from "pg";

// Always connect to RDS Proxy endpoint (not cluster directly)
// RDS Proxy handles connection pooling and failover
const pool = new Pool({
  host: process.env.RDS_PROXY_ENDPOINT!,
  port: 5432,
  database: process.env.DB_NAME!,
  user: process.env.DB_USER!,
  password: process.env.DB_PASSWORD!,

  // Keep app-level pool small — RDS Proxy handles the real pooling
  max: 5,
  idleTimeoutMillis: 30_000,
  connectionTimeoutMillis: 5_000,
  ssl: { rejectUnauthorized: true },  // RDS Proxy enforces TLS
});

pool.on("error", (err) => {
  console.error("Unexpected error on idle client", err);
});

export { pool };

// For Prisma, use connection pooling via connection string
// DATABASE_URL=postgresql://user:pass@proxy-endpoint:5432/db?connection_limit=5&pool_timeout=30

// prisma/schema.prisma
datasource db {
  provider = "postgresql"
  url      = env("DATABASE_URL")
}

Cost Analysis: Aurora Serverless v2 vs Standard Aurora

Key insight: At consistent high load, provisioned wins. At variable load (typical SaaS), Serverless v2 saves 40–60%.

ACU Sizing Guide

1 ACU ≈ 2 GB RAM
Recommended starting points:

Development:   min=0.5  max=4
Staging:       min=1    max=8
Production:    min=2    max=32  (adjust based on observed usage)
High-traffic:  min=4    max=64

Monitor ServerlessDatabaseCapacity CloudWatch metric to tune min/max.

CloudWatch Alarms

# Alert when hitting max ACU (scale-up ceiling)
resource "aws_cloudwatch_metric_alarm" "aurora_max_capacity" {
  alarm_name          = "${var.app_name}-aurora-at-max-capacity"
  comparison_operator = "GreaterThanOrEqualToThreshold"
  evaluation_periods  = 3
  metric_name         = "ServerlessDatabaseCapacity"
  namespace           = "AWS/RDS"
  period              = 60
  statistic           = "Maximum"
  threshold           = var.aurora_max_acu * 0.95  # Alert at 95% of max
  dimensions          = { DBClusterIdentifier = aws_rds_cluster.app.id }
  alarm_description   = "Aurora Serverless approaching max capacity — consider increasing max_capacity"
  alarm_actions       = [aws_sns_topic.alerts.arn]
}
