AWS RDS Proxy: Connection Pooling, IAM Auth, Failover, and Terraform Configuration

PostgreSQL has a hard limit on simultaneous connections — typically 100–1000 depending on instance size. Lambda functions and containerized workloads blow through this limit fast: 500 Lambda concurrent executions × 5 connections each = 2,500 connections, which will crash your database. RDS Proxy sits between your application and the database, multiplexing thousands of application connections into a small pool of real database connections. It also provides IAM-based authentication and cuts failover time from 30–60 seconds to under 10 seconds.

This post covers RDS Proxy in production: connection pooling configuration, IAM database authentication, Lambda integration, and Terraform IaC.

When to Use RDS Proxy

Don't add RDS Proxy if: you have a small number of long-lived server processes (traditional API server). The proxy adds ~1–3ms latency and costs money.

---

1. Terraform Configuration

# infrastructure/rds-proxy/main.tf

# Secrets Manager secret for DB credentials (Proxy reads this)
data "aws_secretsmanager_secret" "db_credentials" {
  name = "/${var.environment}/app/database"
}

# IAM role for RDS Proxy to access Secrets Manager
resource "aws_iam_role" "rds_proxy" {
  name = "${var.project}-rds-proxy-role"

  assume_role_policy = jsonencode({
    Version = "2012-10-17"
    Statement = [{
      Effect    = "Allow"
      Principal = { Service = "rds.amazonaws.com" }
      Action    = "sts:AssumeRole"
    }]
  })
}

resource "aws_iam_role_policy" "rds_proxy_secrets" {
  name = "${var.project}-rds-proxy-secrets"
  role = aws_iam_role.rds_proxy.id

  policy = jsonencode({
    Version = "2012-10-17"
    Statement = [{
      Effect   = "Allow"
      Action   = ["secretsmanager:GetSecretValue"]
      Resource = data.aws_secretsmanager_secret.db_credentials.arn
    }]
  })
}

# RDS Proxy
resource "aws_db_proxy" "main" {
  name                   = "${var.project}-proxy"
  debug_logging          = var.environment != "prod"
  engine_family          = "POSTGRESQL"
  idle_client_timeout    = 1800  # 30 minutes — close idle app connections
  require_tls            = true  # Always encrypt in transit
  role_arn               = aws_iam_role.rds_proxy.arn
  vpc_security_group_ids = [aws_security_group.rds_proxy.id]
  vpc_subnet_ids         = var.private_subnet_ids

  auth {
    auth_scheme               = "SECRETS"
    description               = "DB master credentials"
    iam_auth                  = "REQUIRED"   # Enforce IAM auth (no password connections)
    secret_arn                = data.aws_secretsmanager_secret.db_credentials.arn
  }

  tags = {
    Environment = var.environment
    Project     = var.project
  }
}

# Proxy target group: connects proxy to the Aurora cluster
resource "aws_db_proxy_default_target_group" "main" {
  db_proxy_name = aws_db_proxy.main.name

  connection_pool_config {
    connection_borrow_timeout    = 120        # Max wait for a pool connection (seconds)
    max_connections_percent      = 100        # Use up to 100% of max_connections
    max_idle_connections_percent = 50         # Keep up to 50% idle connections warm
    session_pinning_filters      = [
      # Don't pin for SET commands (allows better multiplexing)
      # "EXCLUDE_VARIABLE_SETS"  ← uncomment if your app uses SET LOCAL
    ]
  }
}

resource "aws_db_proxy_target" "main" {
  db_proxy_name          = aws_db_proxy.main.name
  target_group_name      = aws_db_proxy_default_target_group.main.name
  db_cluster_identifier  = aws_rds_cluster.main.cluster_identifier
}

# Security group for proxy (allow inbound from Lambda/ECS SGs)
resource "aws_security_group" "rds_proxy" {
  name        = "${var.project}-rds-proxy"
  description = "RDS Proxy security group"
  vpc_id      = var.vpc_id

  ingress {
    from_port       = 5432
    to_port         = 5432
    protocol        = "tcp"
    security_groups = [
      aws_security_group.lambda.id,
      aws_security_group.ecs_tasks.id,
    ]
  }

  egress {
    from_port   = 5432
    to_port     = 5432
    protocol    = "tcp"
    cidr_blocks = [var.vpc_cidr]
  }
}

output "proxy_endpoint" {
  value = aws_db_proxy.main.endpoint
}

---

2. IAM Database Authentication

# Allow Lambda/ECS tasks to connect via IAM (no DB password needed)
resource "aws_iam_role_policy" "app_rds_connect" {
  name = "${var.project}-rds-connect"
  role = aws_iam_role.ecs_task.id

  policy = jsonencode({
    Version = "2012-10-17"
    Statement = [{
      Effect   = "Allow"
      Action   = ["rds-db:connect"]
      Resource = [
        # Format: arn:aws:rds-db:region:account:dbuser:proxy-resource-id/db-user
        "arn:aws:rds-db:${var.aws_region}:${data.aws_caller_identity.current.account_id}:dbuser:${aws_db_proxy.main.id}/${var.db_username}"
      ]
    }]
  })
}

// src/lib/db/iam-auth.ts
// Generate IAM auth token for RDS Proxy connection (no hardcoded password)
import { Signer } from '@aws-sdk/rds-signer';

const signer = new Signer({
  hostname: process.env.RDS_PROXY_ENDPOINT!,
  port: 5432,
  region: process.env.AWS_REGION!,
  username: process.env.DB_USERNAME!,
});

// Token expires in 15 minutes — cache and refresh before expiry
let cachedToken: string | null = null;
let tokenExpiresAt = 0;

export async function getIAMAuthToken(): Promise<string> {
  if (cachedToken && Date.now() < tokenExpiresAt - 60_000) {
    return cachedToken;
  }

  cachedToken = await signer.getAuthToken();
  tokenExpiresAt = Date.now() + 15 * 60 * 1000; // 15 minutes
  return cachedToken;
}

// Build database URL with IAM auth token as password
export async function getProxyConnectionUrl(): Promise<string> {
  const token = await getIAMAuthToken();
  const host = process.env.RDS_PROXY_ENDPOINT!;
  const user = process.env.DB_USERNAME!;
  const dbname = process.env.DB_NAME!;

  return `postgresql://${user}:${encodeURIComponent(token)}@${host}:5432/${dbname}?ssl=true&sslmode=require`;
}

// src/lib/db/client.ts — Prisma with RDS Proxy
import { PrismaClient } from '@prisma/client';
import { getProxyConnectionUrl } from './iam-auth';

let prisma: PrismaClient | null = null;

export async function getDb(): Promise<PrismaClient> {
  if (prisma) return prisma;

  const url = await getProxyConnectionUrl();

  prisma = new PrismaClient({
    datasourceUrl: url,
    // Limit connections per instance (proxy multiplexes across instances)
    // connection_limit set in the connection string or via Prisma env vars
  });

  return prisma;
}

// For Lambda: create once at cold start, reuse across invocations
let db: PrismaClient | null = null;

export async function getLambdaDb(): Promise<PrismaClient> {
  if (!db) {
    db = await getDb();
  }
  // IAM token needs refresh every 15 minutes
  // Prisma will reconnect automatically with new token if connection drops
  return db;
}

---

3. Session Pinning (and How to Avoid It)

Session pinning forces the proxy to use the same database connection for the entire client session — which kills the pooling benefit. The proxy pins sessions when it detects connection-modifying statements.

// ❌ Causes session pinning (SET affects connection state):
await db.$executeRaw`SET app.tenant_id = ${tenantId}`;

// ❌ Also pins:
await db.$executeRaw`SET LOCAL app.tenant_id = ${tenantId}`;
// SET LOCAL is transaction-scoped but still pins with RDS Proxy

// ✅ Alternative: pass tenant context via application parameters
// Option 1: Use ROW LEVEL SECURITY with a security-definer function
// Option 2: Include tenant_id in every WHERE clause explicitly
// Option 3: Use session_pinning_filters = ["EXCLUDE_VARIABLE_SETS"] in proxy config
//           (allows SET commands without pinning — less strict)

// If you MUST use SET LOCAL (e.g., for RLS):
// Add EXCLUDE_VARIABLE_SETS to session_pinning_filters in Terraform
// This tells proxy to not pin on SET commands — use carefully

---

4. Lambda Integration

// src/functions/api-handler/handler.ts
// Lambda with RDS Proxy — optimal connection reuse pattern

import { getLambdaDb } from '../../lib/db/client';

let dbInitialized = false;

// Warm up DB connection during init phase (before first invocation)
// Reduces cold-start latency for first request
export const handler = async (event: APIGatewayEvent): Promise<APIGatewayProxyResult> => {
  // Lazy init — connection reused across warm invocations
  const db = await getLambdaDb();

  try {
    const result = await db.product.findMany({
      where: { tenantId: event.requestContext.authorizer?.tenantId },
      take: 20,
    });

    return {
      statusCode: 200,
      headers: { 'Content-Type': 'application/json' },
      body: JSON.stringify(result),
    };
  } catch (err) {
    console.error(err);
    return { statusCode: 500, body: JSON.stringify({ error: 'Internal error' }) };
  }
};

---

Cost Reference

---
