AWS ECR Image Scanning: Vulnerability Detection, Trivy CI, SBOM, and Image Signing with Cosign

Shipping a container image without scanning it is like deploying code without running tests. CVEs in base images and third-party packages are a common attack vector — and they're fixable before deployment. AWS ECR provides two scanning tiers, Trivy adds CI-gate capability, and Cosign ensures images haven't been tampered with between build and deploy.

This guide covers the full supply chain security stack for containers.

ECR Scanning: Basic vs Enhanced

Terraform: ECR with Enhanced Scanning

# terraform/ecr.tf

# Enable enhanced scanning at the registry level
resource "aws_ecr_registry_scanning_configuration" "main" {
  scan_type = "ENHANCED"  # Or "BASIC"

  rule {
    scan_frequency = "SCAN_ON_PUSH"
    repository_filter {
      filter      = "*"           # Scan all repos
      filter_type = "WILDCARD"
    }
  }

  rule {
    scan_frequency = "CONTINUOUS_SCAN"  # Enhanced only
    repository_filter {
      filter      = "prod-*"      # Continuous scan for production images
      filter_type = "WILDCARD"
    }
  }
}

resource "aws_ecr_repository" "app" {
  name                 = "${var.app_name}-app"
  image_tag_mutability = "IMMUTABLE"  # Prevent tag overwriting (security baseline)

  image_scanning_configuration {
    scan_on_push = true
  }

  encryption_configuration {
    encryption_type = "KMS"
    kms_key         = aws_kms_key.ecr.arn
  }

  tags = local.tags
}

# Lifecycle policy: keep last 10 tagged images, expire untagged after 7 days
resource "aws_ecr_lifecycle_policy" "app" {
  repository = aws_ecr_repository.app.name

  policy = jsonencode({
    rules = [
      {
        rulePriority = 1
        description  = "Keep last 10 production images"
        selection = {
          tagStatus     = "tagged"
          tagPrefixList = ["v"]
          countType     = "imageCountMoreThan"
          countNumber   = 10
        }
        action = { type = "expire" }
      },
      {
        rulePriority = 2
        description  = "Expire untagged images after 7 days"
        selection = {
          tagStatus   = "untagged"
          countType   = "sinceImagePushed"
          countUnit   = "days"
          countNumber = 7
        }
        action = { type = "expire" }
      }
    ]
  })
}

# Alert when CRITICAL vulnerabilities are found
resource "aws_cloudwatch_event_rule" "ecr_critical_cve" {
  name = "${var.app_name}-ecr-critical-cve"
  event_pattern = jsonencode({
    source      = ["aws.inspector2"]
    detail-type = ["Inspector2 Finding"]
    detail = {
      severity = [{ exists = true }]
      resources = {
        type = ["AWS_ECR_CONTAINER_IMAGE"]
      }
      severity = ["CRITICAL"]
    }
  })
}

resource "aws_cloudwatch_event_target" "ecr_cve_sns" {
  rule = aws_cloudwatch_event_rule.ecr_critical_cve.name
  arn  = aws_sns_topic.security_alerts.arn
}

Trivy in CI: Block on Critical CVEs

# .github/workflows/build-and-scan.yml
name: Build, Scan, and Push

on:
  push:
    branches: [main]
  pull_request:
    branches: [main]

permissions:
  contents:      read
  id-token:      write   # For OIDC → AWS
  security-events: write # For SARIF upload to GitHub Security

env:
  ECR_REGISTRY: ${{ secrets.AWS_ACCOUNT_ID }}.dkr.ecr.${{ secrets.AWS_REGION }}.amazonaws.com
  IMAGE_NAME:   ${{ secrets.APP_NAME }}-app

jobs:
  build-scan-push:
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v4

      # Build image with build args
      - name: Build Docker image
        run: |
          docker build \
            --build-arg BUILD_DATE=$(date -u +%Y-%m-%dT%H:%M:%SZ) \
            --build-arg GIT_SHA=${{ github.sha }} \
            --tag $IMAGE_NAME:${{ github.sha }} \
            --tag $IMAGE_NAME:latest \
            .

      # Scan with Trivy — fail on CRITICAL CVEs
      - name: Scan with Trivy (fail on CRITICAL)
        uses: aquasecurity/trivy-action@master
        with:
          image-ref:     "${{ env.IMAGE_NAME }}:${{ github.sha }}"
          format:        "table"
          exit-code:     "1"            # Fail CI on vulnerabilities found
          severity:      "CRITICAL"     # Only fail on CRITICAL (not HIGH)
          ignore-unfixed: true          # Skip CVEs with no fix available

      # Also output SARIF for GitHub Security tab
      - name: Scan with Trivy (SARIF output)
        uses: aquasecurity/trivy-action@master
        with:
          image-ref:  "${{ env.IMAGE_NAME }}:${{ github.sha }}"
          format:     "sarif"
          output:     "trivy-results.sarif"
          severity:   "HIGH,CRITICAL"
          ignore-unfixed: true

      - name: Upload SARIF to GitHub Security
        uses: github/codeql-action/upload-sarif@v3
        with:
          sarif_file: trivy-results.sarif

      # Only push if scan passes
      - name: Configure AWS credentials (OIDC)
        if: github.ref == 'refs/heads/main'
        uses: aws-actions/configure-aws-credentials@v4
        with:
          role-to-assume: ${{ secrets.AWS_DEPLOY_ROLE_ARN }}
          aws-region:     ${{ secrets.AWS_REGION }}

      - name: Login to ECR
        if: github.ref == 'refs/heads/main'
        uses: aws-actions/amazon-ecr-login@v2

      - name: Push to ECR
        if: github.ref == 'refs/heads/main'
        run: |
          docker tag $IMAGE_NAME:${{ github.sha }} \
            $ECR_REGISTRY/$IMAGE_NAME:${{ github.sha }}
          docker tag $IMAGE_NAME:${{ github.sha }} \
            $ECR_REGISTRY/$IMAGE_NAME:latest
          docker push $ECR_REGISTRY/$IMAGE_NAME:${{ github.sha }}
          docker push $ECR_REGISTRY/$IMAGE_NAME:latest

SBOM Generation with Syft

A Software Bill of Materials lists every package in your image — required for compliance in many industries.

      # After build, before push
      - name: Generate SBOM with Syft
        uses: anchore/sbom-action@v0
        with:
          image:     "${{ env.IMAGE_NAME }}:${{ github.sha }}"
          format:    spdx-json           # Or cyclonedx-json
          output-file: sbom.spdx.json

      # Upload SBOM as build artifact
      - name: Upload SBOM artifact
        uses: actions/upload-artifact@v4
        with:
          name: sbom-${{ github.sha }}
          path: sbom.spdx.json
          retention-days: 90

      # Optionally: attach SBOM to ECR image
      - name: Attach SBOM to ECR image
        run: |
          oras attach \
            --artifact-type application/vnd.syft+json \
            $ECR_REGISTRY/$IMAGE_NAME:${{ github.sha }} \
            sbom.spdx.json

Image Signing with Cosign

Cosign ensures that the image deployed to ECS/EKS is exactly what was built in CI — no tampering in transit.

      # Install Cosign
      - name: Install Cosign
        uses: sigstore/cosign-installer@v3

      # Sign image with keyless signing (OIDC-based, no private key to manage)
      - name: Sign image with Cosign (keyless)
        if: github.ref == 'refs/heads/main'
        env:
          COSIGN_EXPERIMENTAL: "1"
        run: |
          cosign sign --yes \
            $ECR_REGISTRY/$IMAGE_NAME:${{ github.sha }}

      # Verify before deployment (in deploy job or admission webhook)
      - name: Verify image signature
        if: github.ref == 'refs/heads/main'
        env:
          COSIGN_EXPERIMENTAL: "1"
        run: |
          cosign verify \
            --certificate-identity-regexp="https://github.com/${{ github.repository }}.*" \
            --certificate-oidc-issuer="https://token.actions.githubusercontent.com" \
            $ECR_REGISTRY/$IMAGE_NAME:${{ github.sha }}

Dockerfile Best Practices for Low CVE Surface

# Use minimal base images — fewer packages = fewer CVEs
FROM node:22-alpine AS base

# ✅ Alpine base images have ~50 packages vs ~200 in debian-slim
# ✅ Always pin to a specific digest for reproducibility
# FROM node:22-alpine@sha256:<digest>

# Don't run as root
RUN addgroup -S app && adduser -S app -G app

# Build stage
FROM base AS builder
WORKDIR /app
COPY package*.json ./
RUN npm ci --ignore-scripts      # --ignore-scripts: prevents malicious postinstall scripts
COPY . .
RUN npm run build

# Production stage
FROM base AS runner
WORKDIR /app

# Only copy production artifacts
COPY --from=builder /app/.next/standalone ./
COPY --from=builder /app/.next/static     ./.next/static
COPY --from=builder /app/public           ./public

# Drop to non-root user
USER app

# Health check for container orchestrators
HEALTHCHECK --interval=30s --timeout=5s --start-period=10s --retries=3 \
  CMD wget -qO- http://localhost:3000/api/health || exit 1

EXPOSE 3000
CMD ["node", "server.js"]

Check Scan Results via AWS CLI

# Get scan findings for the latest image in a repository
aws ecr describe-image-scan-findings \
  --repository-name myapp-app \
  --image-id imageTag=latest \
  --query 'imageScanFindings.findingSeverityCounts' \
  --output table

# Output example:
# +-----------+-------+
# | CRITICAL  |     0 |
# | HIGH      |     3 |
# | MEDIUM    |    12 |
# | LOW       |    24 |
# | INFO      |     8 |
# +-----------+-------+

# List CRITICAL findings with CVE IDs
aws ecr describe-image-scan-findings \
  --repository-name myapp-app \
  --image-id imageTag=latest \
  --query 'imageScanFindings.findings[?severity==`CRITICAL`].[name,description,uri]' \
  --output table

Cost Estimates
