API Gateway Patterns: Rate Limiting, Auth, Routing, and When to Build Your Own

An API gateway is the front door to your backend. Every request your clients make passes through it — which means it's also your best opportunity to enforce security, control traffic, and decouple services without scattering that logic across every microservice.

Done right, an API gateway handles authentication, rate limiting, request transformation, and routing in one place. Done wrong, it becomes a monolithic bottleneck that's harder to maintain than the services behind it.

This guide covers the patterns that work, the tradeoffs between managed and custom solutions, and the code to implement them.

---

What an API Gateway Actually Does

Before comparing tools, it helps to be precise about responsibilities. An API gateway sits between clients and backend services and handles:

The key insight: cross-cutting concerns belong at the gateway, not inside every service.

---

Core Pattern 1: JWT Authentication at the Edge

The most common mistake is validating JWTs inside each microservice. That means every service needs the signing key, every service imports a JWT library, and a key rotation requires updating every service.

Push auth to the gateway instead:

// gateway/middleware/auth.ts
import { FastifyRequest, FastifyReply } from 'fastify';
import { jwtVerify, importJWK } from 'jose';

const JWKS_URL = process.env.JWKS_URL!; // e.g. https://auth.example.com/.well-known/jwks.json

let cachedJWKS: any = null;
let jwksExpiry = 0;

async function getJWKS() {
  if (Date.now() < jwksExpiry) return cachedJWKS;
  const res = await fetch(JWKS_URL);
  cachedJWKS = await res.json();
  jwksExpiry = Date.now() + 3_600_000; // cache 1 hour
  return cachedJWKS;
}

export async function authMiddleware(
  request: FastifyRequest,
  reply: FastifyReply
) {
  const authHeader = request.headers.authorization;
  if (!authHeader?.startsWith('Bearer ')) {
    return reply.code(401).send({ error: 'Missing authorization header' });
  }

  const token = authHeader.slice(7);
  try {
    const jwks = await getJWKS();
    const key = await importJWK(jwks.keys[0]);
    const { payload } = await jwtVerify(token, key, {
      issuer: process.env.JWT_ISSUER,
      audience: process.env.JWT_AUDIENCE,
    });

    // Inject identity headers for downstream services
    request.headers['x-user-id'] = payload.sub as string;
    request.headers['x-user-email'] = payload.email as string;
    request.headers['x-user-roles'] = JSON.stringify(payload.roles);
  } catch (err) {
    return reply.code(401).send({ error: 'Invalid or expired token' });
  }
}

The downstream services receive x-user-id and x-user-roles headers — they trust the gateway already validated the token. No JWT library needed inside each service.

---

Core Pattern 2: Rate Limiting with Redis Sliding Window

Per-client rate limiting prevents abuse without punishing everyone when one bad actor spikes traffic. The sliding window algorithm is more accurate than fixed windows (which can allow 2× burst at window boundaries).

// gateway/middleware/rateLimiter.ts
import Redis from 'ioredis';

const redis = new Redis(process.env.REDIS_URL!);

interface RateLimitOptions {
  windowMs: number;   // e.g. 60_000 for 1 minute
  maxRequests: number; // e.g. 100
}

export async function rateLimiter(
  clientId: string,
  options: RateLimitOptions
): Promise<{ allowed: boolean; remaining: number; resetAt: number }> {
  const now = Date.now();
  const windowStart = now - options.windowMs;
  const key = `rl:${clientId}`;

  const pipeline = redis.pipeline();
  pipeline.zremrangebyscore(key, '-inf', windowStart);        // Remove old entries
  pipeline.zadd(key, now.toString(), `${now}-${Math.random()}`); // Add current request
  pipeline.zcard(key);                                         // Count requests in window
  pipeline.expire(key, Math.ceil(options.windowMs / 1000));   // TTL cleanup

  const results = await pipeline.exec();
  const requestCount = results![2][1] as number;

  const allowed = requestCount <= options.maxRequests;
  const remaining = Math.max(0, options.maxRequests - requestCount);
  const resetAt = now + options.windowMs;

  return { allowed, remaining, resetAt };
}

// Usage in route handler
export async function rateLimitMiddleware(
  request: FastifyRequest,
  reply: FastifyReply
) {
  const clientId = request.headers['x-user-id'] as string
    ?? request.ip;

  const { allowed, remaining, resetAt } = await rateLimiter(clientId, {
    windowMs: 60_000,
    maxRequests: 100,
  });

  reply.header('X-RateLimit-Limit', '100');
  reply.header('X-RateLimit-Remaining', remaining.toString());
  reply.header('X-RateLimit-Reset', resetAt.toString());

  if (!allowed) {
    return reply.code(429).send({
      error: 'Rate limit exceeded',
      retryAfter: Math.ceil((resetAt - Date.now()) / 1000),
    });
  }
}

For per-route limits (e.g., login endpoints get stricter limits), pass different maxRequests values per path prefix.

---

Core Pattern 3: Request Routing with Circuit Breaking

Routing maps incoming paths to upstream services. A circuit breaker prevents cascading failures when a downstream service is unhealthy.

// gateway/router.ts
import { FastifyInstance } from 'fastify';
import CircuitBreaker from 'opossum';
import httpProxy from '@fastify/http-proxy';

interface ServiceConfig {
  prefix: string;
  upstream: string;
  timeout: number;
  rateLimit?: { windowMs: number; maxRequests: number };
  auth?: boolean;
}

const services: ServiceConfig[] = [
  { prefix: '/api/users',    upstream: 'http://user-service:3001',    timeout: 5000, auth: true },
  { prefix: '/api/orders',   upstream: 'http://order-service:3002',   timeout: 10000, auth: true },
  { prefix: '/api/products', upstream: 'http://product-service:3003', timeout: 5000, auth: false },
  { prefix: '/api/payments', upstream: 'http://payment-service:3004', timeout: 15000, auth: true },
];

function makeCircuitBreaker(upstream: string, timeout: number) {
  const breaker = new CircuitBreaker(
    async (req: Request) => {
      const res = await fetch(upstream, { signal: AbortSignal.timeout(timeout) });
      if (!res.ok) throw new Error(`Upstream ${upstream} returned ${res.status}`);
      return res;
    },
    {
      timeout,
      errorThresholdPercentage: 50, // Open after 50% failures
      resetTimeout: 30000,           // Try again after 30s
      volumeThreshold: 5,            // Need 5 requests before counting
    }
  );

  breaker.on('open', () => {
    console.warn(`Circuit OPEN for ${upstream}`);
  });
  breaker.on('halfOpen', () => {
    console.info(`Circuit HALF-OPEN for ${upstream} — testing`);
  });

  return breaker;
}

export function registerRoutes(app: FastifyInstance) {
  for (const service of services) {
    const breaker = makeCircuitBreaker(service.upstream, service.timeout);

    app.register(httpProxy, {
      upstream: service.upstream,
      prefix: service.prefix,
      preHandler: async (request, reply) => {
        if (service.auth) {
          await authMiddleware(request, reply);
        }
        await rateLimitMiddleware(request, reply);
      },
      replyOptions: {
        onError: (reply, error) => {
          if (breaker.opened) {
            reply.code(503).send({
              error: 'Service temporarily unavailable',
              service: service.prefix,
            });
          } else {
            reply.code(502).send({ error: 'Bad gateway' });
          }
        },
      },
    });
  }
}

---

Managed vs Custom: When Each Makes Sense

The honest recommendation: Most teams should start with AWS API Gateway or Kong before building custom. The exception is when your auth or routing logic is complex enough that configuring it in a managed tool costs more engineering time than writing it.

---

AWS API Gateway Cost Model

AWS API Gateway charges per request plus data transfer:

Example: 10M requests/month on HTTP API = ~$10/month. At 1B requests/month = ~$960/month. At that scale, a self-managed Kong or Nginx on ECS becomes cheaper.

Kong on ECS Fargate (2 vCPU, 4GB): ~$70/month for the container, unlimited requests.

---

Production Gateway Checklist

Before going live with any API gateway:

• JWT validation at the edge, user identity injected as headers
• Per-client rate limiting with Redis (not in-memory — won't survive restarts or multi-instance)
• Circuit breakers on all upstream service calls
• Request timeouts set per service (payments need longer than reads)
• Structured access logs with request_id, user_id, upstream, latency_ms
• Health check endpoint at /health bypasses auth + rate limiting
• CORS headers configured once at gateway (not in each service)
• Security headers (Strict-Transport-Security, X-Content-Type-Options, etc.)
• mTLS for internal service-to-service (optional but recommended for sensitive services)

---

Cost to Build and Operate

For most startups, AWS API Gateway HTTP API + Lambda authorizer covers the first $1M ARR with minimal ops overhead. For scale-ups handling >100M requests/month with complex routing, self-managed Kong or a custom gateway pays for itself quickly.

---
