TypeScript Discriminated Unions: Pattern Matching, Exhaustiveness Checking, and Real-World Patterns

Discriminated unions are one of TypeScript's most powerful features — they let you model state that can only be in one of several well-defined shapes, with the compiler enforcing that you handle every case. They eliminate entire classes of bugs: impossible states, unhandled cases, and the classic "TypeError: Cannot read properties of undefined" from forgetting to check a nullable field.

This guide covers the patterns, utilities, and real-world applications that make discriminated unions indispensable.

The Basics

// A discriminated union: each variant has a literal "kind" field (the discriminant)
type Shape =
  | { kind: "circle";    radius: number }
  | { kind: "rectangle"; width: number; height: number }
  | { kind: "triangle";  base: number;  height: number };

// TypeScript narrows the type inside each case
function area(shape: Shape): number {
  switch (shape.kind) {
    case "circle":
      return Math.PI * shape.radius ** 2;
    case "rectangle":
      return shape.width * shape.height;
    case "triangle":
      return 0.5 * shape.base * shape.height;
  }
  // TypeScript error if you add a new variant and forget to handle it!
}

Exhaustiveness Checking with never

// The never trick: if you reach the default case, TypeScript
// errors if any variant is unhandled
function assertNever(value: never, message?: string): never {
  throw new Error(message ?? `Unhandled case: ${JSON.stringify(value)}`);
}

function describeShape(shape: Shape): string {
  switch (shape.kind) {
    case "circle":
      return `Circle with radius ${shape.radius}`;
    case "rectangle":
      return `Rectangle ${shape.width}×${shape.height}`;
    case "triangle":
      return `Triangle base ${shape.base}, height ${shape.height}`;
    default:
      return assertNever(shape);
      // If you add kind: "polygon" to Shape without handling it here,
      // TypeScript gives: Argument of type 'Polygon' is not assignable to parameter of type 'never'
  }
}

Result Type for Error Handling

// A typed alternative to throwing exceptions
type Ok<T>  = { readonly ok: true;  value: T };
type Err<E> = { readonly ok: false; error: E };
type Result<T, E = Error> = Ok<T> | Err<E>;

// Constructor helpers
const Ok  = <T>(value: T): Ok<T>   => ({ ok: true,  value });
const Err = <E>(error: E): Err<E>  => ({ ok: false, error });

// Usage: never throws, caller decides what to do with errors
async function fetchUser(id: string): Promise<Result<User, "not_found" | "db_error">> {
  try {
    const user = await prisma.user.findUnique({ where: { id } });
    if (!user) return Err("not_found");
    return Ok(user);
  } catch {
    return Err("db_error");
  }
}

// Caller: exhaustive handling
const result = await fetchUser(userId);

if (result.ok) {
  // TypeScript knows: result.value is User
  console.log(result.value.email);
} else {
  // TypeScript knows: result.error is "not_found" | "db_error"
  switch (result.error) {
    case "not_found":
      return NextResponse.json({ error: "User not found" }, { status: 404 });
    case "db_error":
      return NextResponse.json({ error: "Database error" }, { status: 500 });
    default:
      return assertNever(result.error);
  }
}

Async Result Utilities

// Chain result operations without nested if/else
type AsyncResult<T, E = Error> = Promise<Result<T, E>>;

async function mapResult<T, U, E>(
  result: Result<T, E>,
  fn: (value: T) => Promise<U> | U
): Promise<Result<U, E>> {
  if (!result.ok) return result;
  try {
    return Ok(await fn(result.value));
  } catch (err) {
    // Don't swallow — rethrow unexpected errors
    throw err;
  }
}

async function flatMapResult<T, U, E>(
  result: Result<T, E>,
  fn: (value: T) => AsyncResult<U, E>
): AsyncResult<U, E> {
  if (!result.ok) return result;
  return fn(result.value);
}

// Usage: chained operations
const userResult = await fetchUser(userId);
const profileResult = await flatMapResult(userResult, (user) =>
  fetchProfile(user.profileId)
);
const avatarResult = await mapResult(profileResult, (profile) =>
  buildAvatarUrl(profile.avatarKey)
);

Domain Event Modeling

// Model all domain events as a discriminated union
// Event sourcing, webhooks, and message queues all benefit from this pattern

type WorkspaceEvent =
  | { type: "workspace.created";    workspaceId: string; name: string; ownerId: string }
  | { type: "workspace.renamed";    workspaceId: string; oldName: string; newName: string }
  | { type: "workspace.deleted";    workspaceId: string; deletedBy: string }
  | { type: "member.invited";       workspaceId: string; email: string; role: string; invitedBy: string }
  | { type: "member.joined";        workspaceId: string; userId: string; role: string }
  | { type: "member.removed";       workspaceId: string; userId: string; removedBy: string }
  | { type: "subscription.upgraded"; workspaceId: string; fromPlan: string; toPlan: string }
  | { type: "subscription.cancelled"; workspaceId: string; reason: string };

// All events share a base structure
type BaseEvent = { occurredAt: string; correlationId: string };
type DomainEvent = WorkspaceEvent & BaseEvent;

// Event handler: exhaustive switch
function handleWorkspaceEvent(event: DomainEvent): void {
  switch (event.type) {
    case "workspace.created":
      sendWelcomeEmail(event.ownerId, event.workspaceId);
      break;
    case "workspace.renamed":
      updateSearchIndex(event.workspaceId, event.newName);
      break;
    case "member.invited":
      sendInviteEmail(event.email, event.workspaceId, event.invitedBy);
      break;
    case "member.joined":
      notifyWorkspaceAdmins(event.workspaceId, event.userId);
      break;
    case "subscription.upgraded":
      provisionPlanFeatures(event.workspaceId, event.toPlan);
      break;
    case "subscription.cancelled":
      scheduleDowngrade(event.workspaceId);
      break;
    case "workspace.deleted":
    case "member.removed":
      // No async side-effects needed — audit log handles it
      break;
    default:
      assertNever(event);
  }
}

API Response Types

// Type the full range of API responses
type ApiResponse<T> =
  | { status: "success"; data: T }
  | { status: "error";   code: string; message: string }
  | { status: "loading" };  // Used in React state

// React hook using discriminated union for request state
import { useState, useEffect } from "react";

function useApiData<T>(url: string): ApiResponse<T> {
  const [state, setState] = useState<ApiResponse<T>>({ status: "loading" });

  useEffect(() => {
    fetch(url)
      .then((res) => res.json())
      .then((data) => setState({ status: "success", data }))
      .catch((err) => setState({
        status: "error",
        code: "fetch_error",
        message: err.message,
      }));
  }, [url]);

  return state;
}

// Usage: the component renders differently for each state
function UserProfile({ userId }: { userId: string }) {
  const state = useApiData<User>(`/api/users/${userId}`);

  if (state.status === "loading") return <Skeleton />;
  if (state.status === "error") return <ErrorBanner message={state.message} />;

  // TypeScript knows: state.data is User here
  return <div>{state.data.name}</div>;
}

Form State Machine

// Model form submission as a state machine with discriminated union
type FormState<T, E = string> =
  | { phase: "idle" }
  | { phase: "submitting" }
  | { phase: "success"; data: T }
  | { phase: "error"; error: E };

function useFormState<T, E = string>() {
  const [state, setState] = useState<FormState<T, E>>({ phase: "idle" });

  async function submit(fn: () => Promise<T>): Promise<void> {
    setState({ phase: "submitting" });
    try {
      const data = await fn();
      setState({ phase: "success", data });
    } catch (err) {
      setState({ phase: "error", error: (err as Error).message as E });
    }
  }

  function reset() {
    setState({ phase: "idle" });
  }

  return { state, submit, reset };
}

// Usage:
function InviteForm({ workspaceId }: { workspaceId: string }) {
  const { state, submit, reset } = useFormState<{ inviteId: string }>();

  return (
    <form onSubmit={async (e) => {
      e.preventDefault();
      await submit(() =>
        fetch(`/api/invites`, { method: "POST", body: ... }).then(r => r.json())
      );
    }}>
      {state.phase === "error" && (
        <p className="text-red-600">{state.error}</p>
      )}
      {state.phase === "success" && (
        <p className="text-green-600">Invite sent!</p>
      )}
      <button disabled={state.phase === "submitting"} type="submit">
        {state.phase === "submitting" ? "Sending…" : "Send invite"}
      </button>
    </form>
  );
}

Narrowing Without Switch

// Type predicates for discriminated union narrowing
function isOk<T, E>(result: Result<T, E>): result is Ok<T> {
  return result.ok === true;
}

function isErr<T, E>(result: Result<T, E>): result is Err<E> {
  return result.ok === false;
}

// Usage in arrays: filter to only success results
const results: Result<User>[] = await Promise.all(ids.map(fetchUser));
const users: User[] = results.filter(isOk).map((r) => r.value);
const errors = results.filter(isErr).map((r) => r.error);

Common Pitfalls

// ❌ PITFALL 1: Forgetting the discriminant field
// Without a shared literal field, TypeScript can't narrow
type Bad =
  | { name: string; age: number }      // No discriminant
  | { name: string; email: string };   // TypeScript can't tell these apart

// ✅ Always add a literal discriminant
type Good =
  | { type: "person"; name: string; age: number }
  | { type: "contact"; name: string; email: string };

// ❌ PITFALL 2: Using string instead of string literal for discriminant
type AlsoBad =
  | { type: string; data: User }      // type: string — not narrowable
  | { type: string; data: Product };

// ✅ Use string literals
type GoodEvent =
  | { type: "user_created";    data: User }
  | { type: "product_updated"; data: Product };

// ❌ PITFALL 3: Not handling the default case (no exhaustiveness check)
function handleEvent(event: GoodEvent): void {
  if (event.type === "user_created") {
    createUser(event.data);
  }
  // What if event.type === "product_updated"? Silently ignored!
}

// ✅ Exhaustive switch with assertNever
function handleEventSafe(event: GoodEvent): void {
  switch (event.type) {
    case "user_created":    createUser(event.data);    break;
    case "product_updated": updateProduct(event.data); break;
    default: assertNever(event);
  }
}

Cost and Timeline

Discriminated unions are a zero-cost abstraction — they compile away entirely. The investment is developer education and code review discipline:
