Software Architecture Review: ADRs, Technical Debt, and Fitness Functions

Architecture decisions made without documentation get forgotten, relitigated, and reversed. A team spends a week evaluating PostgreSQL vs. MongoDB, chooses PostgreSQL for strong consistency guarantees, then eighteen months later a new engineer asks "why are we using Postgres? MongoDB would be simpler for this use case." Without a record of the original decision and its context, the debate starts over.

Architecture governance doesn't require a separate Architecture Board or heavyweight RFC processes. It requires three lightweight practices: Architecture Decision Records (ADRs) to document decisions, technical debt registers to make tradeoffs visible, and fitness functions to automatically validate that the architecture stays healthy as the codebase evolves.

---

Architecture Decision Records (ADRs)

An ADR is a short document (one to two pages) that captures: the context, the decision made, the options considered, the tradeoffs, and the consequences. It lives in the repository alongside the code it describes.

ADR Template

# ADR-0014: Use PostgreSQL Row-Level Security for Multi-Tenancy

**Status:** Accepted
**Date:** 2026-03-15
**Deciders:** Backend team, CTO
**Technical Story:** JIRA-2847 — Multi-tenant data isolation

---

## Context

We are building a multi-tenant SaaS product where each tenant's data must
be strictly isolated. We evaluated three approaches:

1. **Separate databases per tenant** — strongest isolation, highest operational cost
2. **Separate schemas per tenant** — good isolation, schema migration complexity
3. **Shared schema with Row-Level Security** — operational simplicity, adequate isolation

We have ~50 tenants today, projecting 500 within 18 months.

---

Decision

Use PostgreSQL Row-Level Security (RLS) with a shared schema.

Set tenant context via SET LOCAL app.current_tenant_id = $1 at the start of each request, inside a transaction. RLS policies enforce that all queries automatically filter to the current tenant.

---

Options Considered

---

Consequences

Positive:

• Single migration run affects all tenants
• Simple connection pooling (one pool for all tenants)
• Easy to add a new tenant (just insert a row)

Negative:

• A bug in RLS policies could expose cross-tenant data — requires thorough testing
• SET LOCAL must be called in every transaction; framework enforcement needed
• Complex analytics queries must explicitly handle tenant_id

Mitigations:

• Automated test suite: integration tests verify RLS isolation per-tenant
• Middleware enforces SET LOCAL before every database operation
• Code review checklist: "Does this query bypass RLS?"

---

Links

• ADR-0010: Chose PostgreSQL over MongoDB
• Implementation PR #847
• RLS documentation

### ADR File Structure

docs/ decisions/ 0001-use-next-js-for-frontend.md 0002-fastify-over-express.md 0003-postgresql-primary-database.md 0004-aws-ecs-fargate-deployment.md ... 0014-rls-multi-tenancy.md README.md ← Index of all ADRs with one-line summaries

### ADR Status Values

- **Proposed** — Under discussion, not yet decided
- **Accepted** — Decision made and in effect
- **Deprecated** — No longer applies (context changed)
- **Superseded by ADR-XXXX** — Replaced by a newer decision

### CLI Tool for ADR Management

```bash
# Install adr-tools
npm install -g adr-tools

# Initialize ADR directory
adr init docs/decisions

# Create new ADR (auto-numbered)
adr new "Use Redis for session storage"
# Creates: docs/decisions/0015-use-redis-for-session-storage.md

# List all ADRs
adr list

# Link related ADRs
adr link 15 Supersedes 8

---

Technical Debt Register

Technical debt without visibility is debt you can't pay down. A technical debt register makes it explicit: what's the debt, who owns it, what's the impact, and when will it be addressed.

# Technical Debt Register

Last updated: 2026-07-01

## Format
Each item: ID | Component | Description | Impact | Owner | Priority | Target Quarter

---

Active Debt

DEBT-001 — Auth Service: JWT secret rotation not implemented

• Impact: Security risk; requires manual key rotation with downtime
• Owner: platform-team
• Priority: High
• Target: Q3 2026
• Estimate: 1 sprint
• Context: Originally planned for v1, deferred to ship on time (ADR-0007)

DEBT-007 — Orders API: N+1 query in order list endpoint

• Impact: Response time degrades linearly with order items count; P99 at 800ms
• Owner: payments-team
• Priority: Medium
• Target: Q3 2026
• Estimate: 2 days
• Context: Quick fix: eager-load items with include in Prisma query

DEBT-013 — Frontend: No error boundaries; uncaught exceptions crash whole app

• Impact: Poor user experience; affects ~2% of sessions (Sentry data)
• Owner: frontend-team
• Priority: Medium
• Target: Q4 2026
• Estimate: 1 week (all major routes)

DEBT-019 — Infrastructure: Manual RDS snapshot process

• Impact: Backup not verified; last restore test was 8 months ago
• Owner: platform-team
• Priority: High
• Target: Q3 2026
• Estimate: 3 days
• Context: AWS Backup should automate + test restore quarterly

---

Resolved This Quarter

• DEBT-004: Replaced custom auth library with Clerk SDK ✅ (2026-06-12)
• DEBT-009: Migrated from CJS to ESM throughout ✅ (2026-06-28)

---

Fitness Functions: Architecture Validation as Tests

Fitness functions are automated checks that verify your architecture stays healthy over time. They run in CI and fail the build when architectural rules are violated — before production.

Dependency Direction Checks

// tests/architecture/dependency-rules.test.ts
import { describe, it, expect } from 'vitest';
import { findImports } from './helpers/find-imports';

describe('Architecture: dependency rules', () => {
  it('domain layer does not import from infrastructure layer', async () => {
    const infraImports = await findImports(
      'src/domain/**/*.ts',
      ['src/infrastructure', 'src/adapters', 'node_modules/prisma'],
    );

    expect(infraImports).toEqual([]);
  });

  it('services layer does not import from routes layer', async () => {
    const violations = await findImports(
      'src/services/**/*.ts',
      ['src/routes', 'src/controllers'],
    );

    expect(violations).toEqual([]);
  });

  it('shared utilities have no app-specific imports', async () => {
    const violations = await findImports(
      'libs/utils/**/*.ts',
      ['src/', 'apps/'],
    );

    expect(violations).toEqual([]);
  });
});

// tests/architecture/helpers/find-imports.ts
import { glob } from 'glob';
import * as fs from 'fs';
import * as path from 'path';

export async function findImports(
  sourcePattern: string,
  forbiddenPrefixes: string[],
): Promise<Array<{ file: string; import: string }>> {
  const files = await glob(sourcePattern);
  const violations: Array<{ file: string; import: string }> = [];

  for (const file of files) {
    const content = fs.readFileSync(file, 'utf-8');
    const importRegex = /(?:import|require)\s*\(?['"](.*?)['"]\)?/g;

    let match;
    while ((match = importRegex.exec(content)) !== null) {
      const importPath = match[1];
      const resolvedPath = path.resolve(path.dirname(file), importPath);

      for (const forbidden of forbiddenPrefixes) {
        if (resolvedPath.includes(forbidden) || importPath.includes(forbidden)) {
          violations.push({ file, import: importPath });
        }
      }
    }
  }

  return violations;
}

Performance Fitness Functions

// tests/architecture/performance-budget.test.ts
import { describe, it, expect } from 'vitest';
import { execSync } from 'child_process';
import * as fs from 'fs';

describe('Architecture: performance budgets', () => {
  it('Next.js bundle size stays within budget', () => {
    // Run build and check bundle sizes
    const buildManifest = JSON.parse(
      fs.readFileSync('.next/build-manifest.json', 'utf-8'),
    );

    // Main app bundle must be <200KB gzipped
    const mainBundles = Object.entries(buildManifest.pages)
      .filter(([page]) => page === '/')
      .flatMap(([, files]) => files as string[]);

    // This is a simplified check — use bundle-analyzer for real measurement
    expect(mainBundles.length).toBeGreaterThan(0);
  });

  it('database schema has indexes on all FK columns', async () => {
    const { db } = await import('@/db');

    // Query PostgreSQL information schema
    const unindexedFKs = await db.query<{ table: string; column: string }>(`
      SELECT
        tc.table_name AS table,
        kcu.column_name AS column
      FROM information_schema.table_constraints tc
      JOIN information_schema.key_column_usage kcu
        ON tc.constraint_name = kcu.constraint_name
      WHERE tc.constraint_type = 'FOREIGN KEY'
        AND NOT EXISTS (
          SELECT 1 FROM pg_indexes
          WHERE tablename = tc.table_name
            AND indexdef LIKE '%' || kcu.column_name || '%'
        )
    `);

    expect(unindexedFKs.rows).toEqual([]);
  });

  it('no API endpoint exceeds 2000ms P95 in load test', () => {
    // Run k6 smoke test and check results
    const result = execSync('k6 run --summary-export=k6-summary.json tests/load/smoke.js', {
      stdio: 'pipe',
    });

    const summary = JSON.parse(fs.readFileSync('k6-summary.json', 'utf-8'));
    const p95 = summary.metrics?.http_req_duration?.values?.['p(95)'];

    expect(p95).toBeLessThan(2000);
  });
});

Security Fitness Functions

# .github/workflows/security-fitness.yml
name: Security Fitness Functions
on: [push, pull_request]

jobs:
  security:
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v4

      # No high/critical vulnerabilities in dependencies
      - name: Dependency audit
        run: npm audit --audit-level=high

      # No secrets committed to repo
      - name: Secret scan
        uses: trufflesecurity/trufflehog@main
        with:
          path: ./
          base: ${{ github.event.repository.default_branch }}

      # No OWASP Top 10 in code
      - name: SAST scan
        uses: SonarSource/sonarcloud-github-action@master
        with:
          projectBaseDir: .
          args: >
            -Dsonar.qualitygate.wait=true

      # License compliance
      - name: License check
        run: npx license-checker --onlyAllow 'MIT;Apache-2.0;BSD-2-Clause;BSD-3-Clause;ISC'

---

Architecture Review Cadence

---

arc42: Lightweight Architecture Documentation

arc42 provides a 12-section template for documenting the architecture of existing systems. Unlike ADRs (which capture decisions), arc42 captures the current state.

# arc42 Architecture Documentation: MyApp

## 1. Introduction and Goals
- Business context and key stakeholders
- Quality goals: reliability >99.9%, P95 <500ms, GDPR compliant

2. Constraints

• Must run on AWS (existing contract)
• Engineering team: 8 developers (no dedicated ops)
• Regulatory: SOC 2 Type II compliance required

3. System Scope and Context

• External systems: Stripe, SendGrid, Auth0, PagerDuty
• Users: SaaS customers, admins, integration partners

4. Solution Strategy

• Monolith-first, microservices only when team/scale demands
• PostgreSQL as primary store, Redis for cache/sessions
• Serverless for async processing (AWS Lambda)

5. Building Block View

• See: docs/architecture/components.png
• API layer (Fastify) → Service layer → Repository layer → PostgreSQL

6. Runtime View

• Order creation flow (sequence diagram)
• Authentication flow (sequence diagram)

7. Deployment View

• AWS ECS Fargate for API, RDS PostgreSQL, ElastiCache Redis
• GitHub Actions CI/CD → ECR → ECS Blue/Green

8. Cross-Cutting Concepts

• Error handling: all errors wrapped in AppError with code/message
• Logging: structured JSON via pino, correlated with trace IDs
• Auth: JWT (access 15min) + refresh tokens (7 days) via HTTP-only cookie

9. Architecture Decisions

• See: docs/decisions/ (ADR index)

10. Quality Requirements

• Reliability: 99.9% uptime SLO
• Performance: P95 API <500ms, P99 <2s
• Security: OWASP Top 10 addressed, SOC 2 Type II

11. Risks and Technical Debt

• See: docs/technical-debt-register.md

12. Glossary

• Tenant: a paying customer organization
• ADR: Architecture Decision Record

---
