SaaS GDPR Engineering: Data Deletion, Consent Management, and Right-to-Erasure Pipelines

GDPR compliance for SaaS is mostly an engineering problem. The legal requirements (right to erasure, data portability, consent records) translate directly into system design decisions: how you store user data, whether you cascade deletes or anonymize, how you sync deletions to third-party systems, and whether your analytics pipeline retains PII.

The biggest mistake: treating GDPR as an afterthought and then trying to bolt deletion pipelines onto a schema that wasn't designed for them.

Data Inventory First

Before writing code, map every place user data lives:

Primary Database (PostgreSQL):
  - users table (email, name, IP, preferences)
  - audit_logs table (user actions — may need to retain)
  - analytics events (anonymize, don't delete)
  - content created by user (may need to retain for other users)

Object Storage (S3):
  - User avatar images
  - Uploaded files
  - Export files

Cache (Redis):
  - Session data
  - User preferences cache

Analytics (Segment, Mixpanel, Amplitude):
  - Clickstream events with user_id
  - Identity profiles

Email (Resend, SendGrid):
  - Email addresses in contact lists
  - Email delivery history

CRM (HubSpot, Salesforce):
  - Contact records
  - Deal history

Logs (CloudWatch, Datadog):
  - May contain PII (IP addresses, emails in error messages)
  - Typically 30–90 day retention policy handles this

Right-to-Erasure Pipeline

// src/services/gdpr/erasure.service.ts

export type ErasureStrategy = "delete" | "anonymize" | "retain";

interface ErasureStep {
  name: string;
  strategy: ErasureStrategy;
  execute: (userId: string) => Promise<void>;
}

export class ErasureService {
  private readonly steps: ErasureStep[] = [
    // Step 1: Anonymize analytics (can't delete — breaks aggregate metrics)
    {
      name: "anonymize-analytics",
      strategy: "anonymize",
      execute: async (userId) => {
        await db.query(
          `UPDATE events
           SET user_id = NULL,
               anonymous_id = $2,  -- Replace with stable but non-identifying hash
               properties = properties - 'email' - 'name' - 'phone'
           WHERE user_id = $1`,
          [userId, `anon-${hashUserId(userId)}`]
        );
      },
    },

    // Step 2: Delete user-generated content (or anonymize if other users depend on it)
    {
      name: "handle-content",
      strategy: "anonymize",
      execute: async (userId) => {
        // Comments: anonymize (other users see "[Deleted User]")
        await db.query(
          `UPDATE comments
           SET user_id = NULL,
               author_name = '[Deleted User]',
               author_email = NULL
           WHERE user_id = $1`,
          [userId]
        );

        // Private files: delete
        const { rows: files } = await db.query<{ s3_key: string }>(
          "SELECT s3_key FROM user_files WHERE user_id = $1 AND visibility = 'private'",
          [userId]
        );

        for (const file of files) {
          await s3.deleteObject({
            Bucket: process.env.S3_BUCKET!,
            Key: file.s3_key,
          });
        }

        await db.query(
          "DELETE FROM user_files WHERE user_id = $1 AND visibility = 'private'",
          [userId]
        );
      },
    },

    // Step 3: Delete S3 avatar
    {
      name: "delete-avatar",
      strategy: "delete",
      execute: async (userId) => {
        await s3.deleteObject({
          Bucket: process.env.S3_BUCKET!,
          Key: `avatars/${userId}.webp`,
        });
      },
    },

    // Step 4: Revoke all sessions
    {
      name: "revoke-sessions",
      strategy: "delete",
      execute: async (userId) => {
        await redis.del(`session:${userId}:*`); // Delete all session keys
        await db.query(
          "DELETE FROM refresh_tokens WHERE user_id = $1",
          [userId]
        );
      },
    },

    // Step 5: Notify third-party services
    {
      name: "notify-third-parties",
      strategy: "delete",
      execute: async (userId) => {
        const { rows } = await db.query<{ email: string }>(
          "SELECT email FROM users WHERE id = $1",
          [userId]
        );
        if (!rows[0]) return;

        const email = rows[0].email;

        // Delete from email service
        await Promise.allSettled([
          resend.contacts.remove({ email, audienceId: process.env.RESEND_AUDIENCE_ID! }),
          hubspot.crm.contacts.basicApi.archive(email),
          segment.identify({ userId, traits: { $delete: true } }),
        ]);
      },
    },

    // Step 6: Anonymize audit logs (retain for legal compliance, remove PII)
    {
      name: "anonymize-audit-logs",
      strategy: "anonymize",
      execute: async (userId) => {
        await db.query(
          `UPDATE audit_log_entries
           SET user_id = NULL,
               user_email = NULL,
               ip_address = NULL,
               user_agent = NULL
           WHERE user_id = $1`,
          [userId]
        );
      },
    },

    // Step 7: Delete the user record (last — all FK references cleaned first)
    {
      name: "delete-user-record",
      strategy: "delete",
      execute: async (userId) => {
        await db.query("DELETE FROM users WHERE id = $1", [userId]);
      },
    },
  ];

  async executeErasure(userId: string): Promise<ErasureResult> {
    // Log the erasure request for compliance
    const erasureId = await this.createErasureRecord(userId);
    const results: { step: string; success: boolean; error?: string }[] = [];

    for (const step of this.steps) {
      try {
        await step.execute(userId);
        results.push({ step: step.name, success: true });
      } catch (error) {
        // Log failure but continue — partial erasure is better than none
        const message = error instanceof Error ? error.message : String(error);
        results.push({ step: step.name, success: false, error: message });
        console.error(`Erasure step ${step.name} failed for user ${userId}:`, error);
      }
    }

    await this.completeErasureRecord(erasureId, results);

    const allSucceeded = results.every((r) => r.success);
    if (!allSucceeded) {
      // Alert engineering team — incomplete erasure needs manual review
      await alertErasureFailure(userId, erasureId, results);
    }

    return { erasureId, completed: allSucceeded, steps: results };
  }

  private async createErasureRecord(userId: string): Promise<string> {
    const { rows } = await db.query<{ id: string }>(
      `INSERT INTO gdpr_erasure_requests
       (user_id, requested_at, status)
       VALUES ($1, NOW(), 'in_progress')
       RETURNING id`,
      [userId]
    );
    return rows[0].id;
  }
}

Consent Management

-- Consent events — append-only ledger (never update, only insert)
CREATE TABLE consent_events (
  id           UUID         PRIMARY KEY DEFAULT gen_random_uuid(),
  user_id      UUID         NOT NULL,
  consent_type TEXT         NOT NULL,
  -- Types: 'marketing_email' | 'analytics' | 'functional' | 'personalization'
  action       TEXT         NOT NULL,  -- 'granted' | 'revoked'
  source       TEXT         NOT NULL,  -- 'signup_form' | 'settings_page' | 'api'
  ip_address   INET,
  user_agent   TEXT,
  recorded_at  TIMESTAMPTZ  NOT NULL DEFAULT NOW(),
  -- Store the consent text shown to the user at time of consent
  consent_version TEXT      NOT NULL,
  consent_text    TEXT      NOT NULL
);

-- Current consent state: last action per user per type
CREATE VIEW current_consent AS
SELECT DISTINCT ON (user_id, consent_type)
  user_id,
  consent_type,
  action AS current_state,
  recorded_at AS last_updated,
  consent_version
FROM consent_events
ORDER BY user_id, consent_type, recorded_at DESC;

// src/services/gdpr/consent.service.ts

export type ConsentType = "marketing_email" | "analytics" | "functional" | "personalization";
export type ConsentAction = "granted" | "revoked";

export async function recordConsent(params: {
  userId: string;
  type: ConsentType;
  action: ConsentAction;
  source: string;
  ipAddress: string;
  userAgent: string;
  consentVersion: string;   // Version of your Privacy Policy / cookie banner
  consentText: string;      // Exact text shown to the user
}): Promise<void> {
  await db.query(
    `INSERT INTO consent_events
     (user_id, consent_type, action, source, ip_address, user_agent,
      consent_version, consent_text)
     VALUES ($1, $2, $3, $4, $5, $6, $7, $8)`,
    [
      params.userId, params.type, params.action, params.source,
      params.ipAddress, params.userAgent,
      params.consentVersion, params.consentText,
    ]
  );

  // If analytics consent revoked: anonymize historical data
  if (params.type === "analytics" && params.action === "revoked") {
    await anonymizeUserAnalytics(params.userId);
  }
}

export async function getUserConsents(userId: string): Promise<
  Record<ConsentType, { granted: boolean; lastUpdated: Date }>
> {
  const { rows } = await db.query(
    "SELECT * FROM current_consent WHERE user_id = $1",
    [userId]
  );

  return Object.fromEntries(
    rows.map((row) => [
      row.consent_type,
      { granted: row.current_state === "granted", lastUpdated: row.last_updated },
    ])
  ) as Record<ConsentType, { granted: boolean; lastUpdated: Date }>;
}

Data Subject Access Request (DSAR)

// src/services/gdpr/dsar.service.ts
// Generate a complete data export for a user

export async function generateDataExport(userId: string): Promise<string> {
  const [user, events, files, consents, subscriptions] = await Promise.all([
    db.query("SELECT * FROM users WHERE id = $1", [userId]),
    db.query(
      "SELECT event_type, occurred_at, properties FROM events WHERE user_id = $1 ORDER BY occurred_at DESC LIMIT 10000",
      [userId]
    ),
    db.query(
      "SELECT filename, created_at, file_size FROM user_files WHERE user_id = $1",
      [userId]
    ),
    db.query(
      "SELECT consent_type, action, recorded_at, consent_version FROM consent_events WHERE user_id = $1 ORDER BY recorded_at DESC",
      [userId]
    ),
    db.query(
      "SELECT plan, status, created_at FROM subscriptions WHERE user_id = $1",
      [userId]
    ),
  ]);

  const exportData = {
    exportedAt: new Date().toISOString(),
    exportVersion: "1.0",
    userData: {
      profile: user.rows[0],
      activityHistory: events.rows,
      files: files.rows,
      consentHistory: consents.rows,
      subscriptions: subscriptions.rows,
    },
  };

  // Upload to a time-limited S3 presigned URL (expires in 7 days)
  const key = `gdpr-exports/${userId}/${Date.now()}.json`;
  await s3.putObject({
    Bucket: process.env.GDPR_EXPORT_BUCKET!,
    Key: key,
    Body: JSON.stringify(exportData, null, 2),
    ContentType: "application/json",
    // Auto-delete after 30 days
    Expires: new Date(Date.now() + 30 * 24 * 3600 * 1000),
  });

  const downloadUrl = await s3.getSignedUrlPromise("getObject", {
    Bucket: process.env.GDPR_EXPORT_BUCKET!,
    Key: key,
    Expires: 7 * 24 * 3600, // URL valid for 7 days
  });

  return downloadUrl;
}

GDPR Engineering Checklist

Data Inventory:
□ All PII data stores documented
□ Data retention periods defined per table
□ Third-party processors listed in DPA

Right to Erasure:
□ Deletion pipeline covers all data stores
□ Third-party deletion notifications implemented
□ Erasure requests logged with completion status
□ Partial erasure triggers alert for manual review

Consent:
□ Consent stored as append-only event log
□ Consent text + version recorded at time of consent
□ Analytics disabled when consent revoked
□ Consent UI surfaces in settings for self-service update

DSAR:
□ Export covers all personal data
□ Export delivered within 30 days (legal requirement)
□ Export download link time-limited

Data Minimization:
□ IP addresses hashed or truncated in analytics
□ Logs don't contain raw emails or names
□ Telemetry uses anonymous IDs, not emails
