React Virtual Table: Rendering 100k Rows with TanStack Virtual, Dynamic Heights, and Sticky Headers

Rendering 100,000 rows in a DOM table kills the browser. Each <tr> and <td> is a DOM node — a 100k-row table with 10 columns creates 1 million DOM nodes before any layout or paint happens. TanStack Virtual solves this by rendering only the rows that are visible in the viewport (typically 20–40 rows), recycling them as the user scrolls.

Setup

npm install @tanstack/react-virtual @tanstack/react-table

Fixed-Height Virtual Table

// components/virtual-table/virtual-table.tsx
"use client";

import {
  useReactTable,
  getCoreRowModel,
  getSortedRowModel,
  getFilteredRowModel,
  flexRender,
  type ColumnDef,
  type SortingState,
} from "@tanstack/react-table";
import { useVirtualizer } from "@tanstack/react-virtual";
import { useRef, useState, useMemo } from "react";
import { ArrowUp, ArrowDown, ArrowUpDown } from "lucide-react";

interface VirtualTableProps<TData> {
  data:     TData[];
  columns:  ColumnDef<TData>[];
  rowHeight?: number;  // Fixed row height in px (default: 40)
}

export function VirtualTable<TData>({
  data,
  columns,
  rowHeight = 40,
}: VirtualTableProps<TData>) {
  const [sorting,   setSorting]   = useState<SortingState>([]);
  const [globalFilter, setGlobalFilter] = useState("");

  const table = useReactTable({
    data,
    columns,
    state:             { sorting, globalFilter },
    onSortingChange:   setSorting,
    onGlobalFilterChange: setGlobalFilter,
    getCoreRowModel:      getCoreRowModel(),
    getSortedRowModel:    getSortedRowModel(),
    getFilteredRowModel:  getFilteredRowModel(),
  });

  const { rows } = table.getRowModel();

  // Ref on the scrollable container (not the table itself)
  const parentRef = useRef<HTMLDivElement>(null);

  const virtualizer = useVirtualizer({
    count:         rows.length,
    getScrollElement: () => parentRef.current,
    estimateSize:  () => rowHeight,    // Fixed height
    overscan:      5,                  // Render 5 extra rows above/below viewport
  });

  const virtualRows  = virtualizer.getVirtualItems();
  const totalHeight  = virtualizer.getTotalSize();   // Total scrollable height

  // Padding to position visible rows correctly within the total height
  const paddingTop    = virtualRows.length > 0 ? virtualRows[0].start    : 0;
  const paddingBottom = virtualRows.length > 0
    ? totalHeight - virtualRows[virtualRows.length - 1].end
    : 0;

  return (
    <div className="flex flex-col h-full border border-gray-200 rounded-xl overflow-hidden">
      {/* Search bar */}
      <div className="px-4 py-3 border-b border-gray-200 bg-gray-50">
        <input
          type="text"
          value={globalFilter}
          onChange={(e) => setGlobalFilter(e.target.value)}
          placeholder={`Search ${data.length.toLocaleString()} rows…`}
          className="w-72 border border-gray-300 rounded-lg px-3 py-1.5 text-sm focus:outline-none focus:ring-2 focus:ring-blue-500"
        />
      </div>

      {/* Sticky header */}
      <div className="overflow-x-auto">
        <table className="w-full border-collapse table-fixed">
          <thead className="sticky top-0 bg-white z-10 border-b border-gray-200">
            {table.getHeaderGroups().map((headerGroup) => (
              <tr key={headerGroup.id}>
                {headerGroup.headers.map((header) => (
                  <th
                    key={header.id}
                    style={{ width: header.getSize() }}
                    className="px-4 py-3 text-left text-xs font-semibold text-gray-500 uppercase tracking-wider select-none"
                    onClick={header.column.getToggleSortingHandler()}
                  >
                    <div className="flex items-center gap-1.5">
                      {flexRender(header.column.columnDef.header, header.getContext())}
                      {header.column.getCanSort() && (
                        <span className="text-gray-400">
                          {header.column.getIsSorted() === "asc"  ? <ArrowUp   className="w-3.5 h-3.5" /> :
                           header.column.getIsSorted() === "desc" ? <ArrowDown className="w-3.5 h-3.5" /> :
                           <ArrowUpDown className="w-3.5 h-3.5" />}
                        </span>
                      )}
                    </div>
                  </th>
                ))}
              </tr>
            ))}
          </thead>
        </table>
      </div>

      {/* Virtualized body */}
      <div ref={parentRef} className="flex-1 overflow-auto">
        <table className="w-full border-collapse table-fixed">
          <tbody>
            {paddingTop > 0 && (
              <tr><td style={{ height: `${paddingTop}px` }} colSpan={columns.length} /></tr>
            )}
            {virtualRows.map((virtualRow) => {
              const row = rows[virtualRow.index];
              return (
                <tr
                  key={row.id}
                  data-index={virtualRow.index}
                  className="border-b border-gray-100 hover:bg-blue-50/50 transition-colors"
                >
                  {row.getVisibleCells().map((cell) => (
                    <td
                      key={cell.id}
                      style={{ width: cell.column.getSize() }}
                      className="px-4 py-0 text-sm text-gray-700 overflow-hidden text-ellipsis whitespace-nowrap"
                    >
                      {flexRender(cell.column.columnDef.cell, cell.getContext())}
                    </td>
                  ))}
                </tr>
              );
            })}
            {paddingBottom > 0 && (
              <tr><td style={{ height: `${paddingBottom}px` }} colSpan={columns.length} /></tr>
            )}
          </tbody>
        </table>
      </div>

      {/* Footer: row count */}
      <div className="px-4 py-2 border-t border-gray-200 bg-gray-50 text-xs text-gray-500">
        {rows.length.toLocaleString()} rows{" "}
        {rows.length !== data.length && `(filtered from ${data.length.toLocaleString()})`}
      </div>
    </div>
  );
}

Dynamic Row Heights

// When rows have variable heights (e.g., multi-line descriptions)
// components/virtual-table/variable-height-table.tsx

import { useVirtualizer } from "@tanstack/react-virtual";
import { useRef, useCallback } from "react";

export function VariableHeightTable<TData>({ rows }: { rows: TData[] }) {
  const parentRef = useRef<HTMLDivElement>(null);
  const rowSizeMap = useRef<Map<number, number>>(new Map());

  // Called by rows to report their actual measured height
  const measureRow = useCallback((index: number, el: HTMLElement | null) => {
    if (!el) return;
    const height = el.getBoundingClientRect().height;
    if (rowSizeMap.current.get(index) !== height) {
      rowSizeMap.current.set(index, height);
      virtualizer.measure(); // Tell virtualizer to recalculate
    }
  }, []);

  const virtualizer = useVirtualizer({
    count:            rows.length,
    getScrollElement: () => parentRef.current,
    estimateSize:     (index) => rowSizeMap.current.get(index) ?? 60, // Initial estimate
    measureElement:   (el) => el.getBoundingClientRect().height,       // Measure actual DOM element
    overscan:         3,
  });

  return (
    <div ref={parentRef} className="h-[600px] overflow-auto">
      <div style={{ height: `${virtualizer.getTotalSize()}px`, position: "relative" }}>
        {virtualizer.getVirtualItems().map((virtualItem) => (
          <div
            key={virtualItem.key}
            data-index={virtualItem.index}
            ref={(el) => virtualizer.measureElement(el)}  // Auto-measure
            style={{
              position:  "absolute",
              top:       0,
              left:      0,
              width:     "100%",
              transform: `translateY(${virtualItem.start}px)`,  // Position via transform
            }}
            className="border-b border-gray-100 px-4 py-3"
          >
            {/* Row content — height is determined by content */}
            <RowContent item={rows[virtualItem.index]} />
          </div>
        ))}
      </div>
    </div>
  );
}

Row Selection

// Add row selection to the fixed-height virtual table

import { type RowSelectionState } from "@tanstack/react-table";

// In VirtualTable:
const [rowSelection, setRowSelection] = useState<RowSelectionState>({});

const selectionColumn: ColumnDef<TData> = {
  id:     "select",
  size:   40,
  header: ({ table }) => (
    <input
      type="checkbox"
      checked={table.getIsAllRowsSelected()}
      indeterminate={table.getIsSomeRowsSelected()}
      onChange={table.getToggleAllRowsSelectedHandler()}
      className="rounded border-gray-300"
    />
  ),
  cell: ({ row }) => (
    <input
      type="checkbox"
      checked={row.getIsSelected()}
      onChange={row.getToggleSelectedHandler()}
      className="rounded border-gray-300"
      onClick={(e) => e.stopPropagation()} // Don't trigger row click
    />
  ),
};

// Combine with other columns:
// const allColumns = [selectionColumn, ...columns];

// Get selected rows:
// const selectedRows = table.getSelectedRowModel().rows.map(r => r.original);

Example: 100k Row Table

// Demo: generate 100,000 rows and render without freezing
// pages/demo/large-table.tsx
"use client";

import { useMemo } from "react";
import { VirtualTable } from "@/components/virtual-table/virtual-table";
import type { ColumnDef } from "@tanstack/react-table";

interface Row {
  id:        number;
  name:      string;
  email:     string;
  plan:      string;
  mrr:       number;
  createdAt: string;
}

export default function LargeTableDemo() {
  // Generate 100k rows (in production, these come from an API)
  const data = useMemo<Row[]>(() => {
    return Array.from({ length: 100_000 }, (_, i) => ({
      id:        i + 1,
      name:      `Workspace ${i + 1}`,
      email:     `user${i + 1}@example.com`,
      plan:      ["free", "starter", "growth", "enterprise"][i % 4],
      mrr:       Math.round(Math.random() * 1000 * 100) / 100,
      createdAt: new Date(Date.now() - i * 86400_000).toLocaleDateString(),
    }));
  }, []);

  const columns = useMemo<ColumnDef<Row>[]>(() => [
    { accessorKey: "id",        header: "ID",         size: 80,  enableSorting: true },
    { accessorKey: "name",      header: "Name",        size: 200, enableSorting: true },
    { accessorKey: "email",     header: "Email",       size: 250, enableSorting: true },
    { accessorKey: "plan",      header: "Plan",        size: 100, enableSorting: true },
    {
      accessorKey: "mrr",
      header:      "MRR",
      size:        120,
      enableSorting: true,
      cell: ({ getValue }) => `$${(getValue() as number).toFixed(2)}`,
    },
    { accessorKey: "createdAt", header: "Created",     size: 150, enableSorting: true },
  ], []);

  return (
    <div className="h-screen p-6 flex flex-col gap-4">
      <h1 className="text-2xl font-bold">
        100,000 Row Virtual Table
      </h1>
      <div className="flex-1 min-h-0">
        <VirtualTable data={data} columns={columns} rowHeight={40} />
      </div>
    </div>
  );
}

Cost and Timeline Estimates

See Also

• React Data Tables
• React Performance Optimization
• Next.js INP Optimization
• React Keyboard Shortcuts
• SaaS Usage Analytics

---

Working With Viprasol

Virtual tables require getting the layout right: the header must be sticky (sticky top-0 z-10) outside the scrollable body div, the body needs a separate ref for the virtualizer's getScrollElement, and padding rows must be inserted above and below the virtual items to maintain correct scroll position. For dynamic heights, the measureElement callback tells the virtualizer the true DOM height after render.

What we deliver:

• VirtualTable<TData>: generic component with useReactTable + useVirtualizer
• estimateSize: () => rowHeight for fixed heights, measureElement for dynamic
• Padding rows (paddingTop + paddingBottom) to maintain scroll correctness
• Sticky header: separate <div> with overflow-x-auto + table-fixed outside scroll container
• Global filter + per-column sort with ArrowUp/ArrowDown/ArrowUpDown icons
• VariableHeightTable: translateY positioning + ref={(el) => virtualizer.measureElement(el)}
• Row selection column with header checkbox (indeterminate state for partial selection)
• 100k row demo: Array.from({ length: 100_000 }) with useMemo
