Platform Engineering: Internal Developer Platforms, Backstage, and Golden Paths

Platform engineering is the discipline of building internal products for developers — the infrastructure, tooling, and workflows that allow application teams to ship faster without each team reinventing deployment pipelines, observability, and service scaffolding.

The core concept: treat developers as customers. Build a product (the Internal Developer Platform, or IDP) that makes the right way to do things also the easy way.

---

When Platform Engineering Makes Sense

Platform teams make sense when you have:

• 50+ engineers spending time on infrastructure and DevOps concerns instead of product
• 5+ application teams each building their own CI/CD pipelines, monitoring, and deployment tooling
• Repeated patterns across services (every team sets up the same Dockerfile, GitHub Actions workflow, alerting rules)
• Cognitive load from infrastructure slowing feature delivery

For smaller organizations: a well-documented set of templates and runbooks achieves most of the benefit without a dedicated platform team.

---

The Internal Developer Platform Stack

A mature IDP typically includes:

---

Backstage: The Service Catalog

Backstage (Spotify, open-source) is the most widely adopted IDP framework. It provides a service catalog, software templates, and a plugin ecosystem.

Install and configure Backstage:

npx @backstage/create-app@latest
cd my-backstage-app
yarn dev  # Starts at http://localhost:3000

Register a service in the catalog:

# catalog-info.yaml — in every service repository
apiVersion: backstage.io/v1alpha1
kind: Component
metadata:
  name: payment-service
  description: Handles all payment processing — Stripe integration, webhooks, refunds
  annotations:
    github.com/project-slug: yourorg/payment-service
    backstage.io/techdocs-ref: dir:.
    pagerduty.com/service-id: P12345
    datadog/dashboard-url: https://app.datadoghq.com/dashboard/xxx
  tags:
    - typescript
    - payments
    - critical
  links:
    - url: https://payment-service.internal.yourapp.com/health
      title: Health Check
    - url: https://grafana.yourapp.com/d/payment
      title: Grafana Dashboard
spec:
  type: service
  lifecycle: production
  owner: payments-team
  system: billing
  dependsOn:
    - resource:default/payments-postgres
    - resource:default/stripe-api
  providesApis:
    - payment-api

Backstage Software Template (Golden Path):

# templates/typescript-service/template.yaml
apiVersion: scaffolder.backstage.io/v1beta3
kind: Template
metadata:
  name: typescript-microservice
  title: TypeScript Microservice
  description: Create a new TypeScript service with Fastify, PostgreSQL, and CI/CD pre-configured
  tags: [typescript, fastify, postgresql]
spec:
  owner: platform-team
  type: service

  parameters:
    - title: Service Information
      required: [name, description, owner]
      properties:
        name:
          type: string
          pattern: '^[a-z][a-z0-9-]*$'
          description: Service name (kebab-case)
        description:
          type: string
        owner:
          type: string
          ui:field: OwnerPicker
          ui:options:
            allowedKinds: [Group]
        needsDatabase:
          type: boolean
          default: false
          title: Include PostgreSQL database?

  steps:
    - id: fetch-template
      name: Fetch Template
      action: fetch:template
      input:
        url: ./skeleton
        values:
          name: ${{ parameters.name }}
          description: ${{ parameters.description }}
          owner: ${{ parameters.owner }}
          needsDatabase: ${{ parameters.needsDatabase }}

    - id: create-repo
      name: Create GitHub Repository
      action: github:repo:create
      input:
        repoUrl: github.com?repo=${{ parameters.name }}&owner=yourorg
        defaultBranch: main
        topics: [typescript, microservice]

    - id: push-to-repo
      name: Push to Repository
      action: github:repo:push
      input:
        repoUrl: github.com?repo=${{ parameters.name }}&owner=yourorg
        defaultBranch: main

    - id: register-catalog
      name: Register in Catalog
      action: catalog:register
      input:
        repoContentsUrl: https://github.com/yourorg/${{ parameters.name }}/blob/main
        catalogInfoPath: /catalog-info.yaml

  output:
    links:
      - title: View in Backstage
        entityRef: ${{ steps.register-catalog.output.entityRef }}
      - title: GitHub Repository
        url: ${{ steps.create-repo.output.remoteUrl }}

What the generated skeleton includes:

skeleton/
├── .github/
│   └── workflows/
│       └── ci.yml          ← Pre-configured CI pipeline
├── src/
│   ├── app.ts              ← Fastify server setup
│   ├── config.ts           ← Zod config validation
│   └── routes/
│       └── health.ts       ← Liveness + readiness probes
├── ${% if values.needsDatabase %}
├── prisma/
│   └── schema.prisma       ← PostgreSQL schema
${% endif %}
├── Dockerfile              ← Multi-stage, non-root user
├── catalog-info.yaml       ← Auto-registered in Backstage
├── terraform/              ← ECS task definition, IAM roles
└── README.md               ← Generated from template

---

Golden Path CI/CD (Reusable GitHub Actions)

Instead of every team writing their own GitHub Actions workflow, provide shared workflows:

# .github/workflows/shared-build-push.yml
# Published in your platform org: yourorg/platform-workflows

name: Build and Push Docker Image

on:
  workflow_call:
    inputs:
      service-name:
        required: true
        type: string
      dockerfile:
        required: false
        type: string
        default: './Dockerfile'
    secrets:
      aws-role-arn:
        required: true

jobs:
  build-and-push:
    runs-on: ubuntu-latest
    permissions:
      id-token: write
      contents: read

    steps:
      - uses: actions/checkout@v4

      - name: Configure AWS credentials (OIDC)
        uses: aws-actions/configure-aws-credentials@v4
        with:
          role-to-assume: ${{ secrets.aws-role-arn }}
          aws-region: us-east-1

      - name: Login to ECR
        uses: aws-actions/amazon-ecr-login@v2

      - name: Build and push
        uses: docker/build-push-action@v5
        with:
          push: true
          tags: |
            ${{ env.ECR_REGISTRY }}/${{ inputs.service-name }}:${{ github.sha }}
            ${{ env.ECR_REGISTRY }}/${{ inputs.service-name }}:latest
          cache-from: type=gha
          cache-to: type=gha,mode=max

# Service team's workflow — 10 lines instead of 80
name: CI

on:
  push:
    branches: [main]

jobs:
  build:
    uses: yourorg/platform-workflows/.github/workflows/shared-build-push.yml@main
    with:
      service-name: payment-service
    secrets:
      aws-role-arn: ${{ secrets.AWS_ROLE_ARN }}

---

Self-Service Infrastructure with Crossplane

Crossplane lets application teams provision cloud resources (databases, queues, storage) via Kubernetes CRDs — without writing Terraform or opening tickets to the platform team:

# Application team creates this in their namespace
# Platform team's Crossplane compositions handle the actual provisioning
apiVersion: database.platform.yourorg.com/v1alpha1
kind: PostgreSQLInstance
metadata:
  name: payment-db
  namespace: payments-team
spec:
  parameters:
    size: small       # Platform translates to RDS instance type
    storage: 20       # GB
    environment: production
    backupRetentionDays: 14
  writeConnectionSecretsToRef:
    name: payment-db-creds  # Secret auto-created in team namespace

The platform team defines what "small" means (db.t3.small), what backup retention they require, which VPC it deploys to — application teams just say what they need.

---

Measuring Platform Impact

-- Track time engineers spend on infrastructure vs product
-- (Survey data + ticket data from your ticketing system)

SELECT
    month,
    AVG(infra_ticket_hours) AS avg_hours_on_infra,
    AVG(product_ticket_hours) AS avg_hours_on_product,
    ROUND(AVG(infra_ticket_hours) / NULLIF(AVG(infra_ticket_hours + product_ticket_hours), 0) * 100, 1)
      AS pct_time_on_infra
FROM engineering_time_tracking
GROUP BY month
ORDER BY month;

-- Target: < 10% of engineering time on infrastructure concerns
-- (vs. industry average of 20-30% without a platform team)

Key platform metrics:

• Time to first deployment for new services (Golden Path target: < 1 day, from idea to running in staging)
• Cognitive load score (quarterly survey: "How confident are you that you understand how to deploy your service?")
• Infrastructure ticket volume (should decrease as self-service matures)
• MTTR (platform's contribution to faster incident response via standardized observability)

---
