PostgreSQL Replication: Streaming Replication, Read Replicas, Logical Replication, and Failover

A single PostgreSQL primary is a single point of failure and a single write bottleneck. Replication solves both: read replicas distribute read load, and standby servers provide failover capability. Understanding the types of replication and their tradeoffs is essential for production database architecture.

---

Replication Types

---

Streaming Replication Setup

# Primary server: postgresql.conf
wal_level = replica                    # Minimum for replication
max_wal_senders = 10                   # Max concurrent replication connections
wal_keep_size = 1GB                    # Keep 1GB of WAL for replicas to catch up
synchronous_commit = on                # Async replicas: 'off' for better write performance
                                       # Sync replicas: 'on' guarantees no data loss on failover

# For synchronous replication (zero data loss, but slower writes):
# synchronous_standby_names = 'FIRST 1 (replica1, replica2)'

# Primary server: pg_hba.conf — allow replication connections
host  replication  replicator  10.0.0.0/8  scram-sha-256

# On primary: create replication user
psql -c "CREATE USER replicator REPLICATION LOGIN ENCRYPTED PASSWORD 'strong-password';"

# On replica: create base backup from primary
pg_basebackup \
  --host=primary-db.internal \
  --username=replicator \
  --pgdata=/var/lib/postgresql/17/main \
  --wal-method=stream \
  --checkpoint=fast \
  --progress \
  --verbose

# Replica server: postgresql.conf
hot_standby = on                       # Allow reads on replica (essential for read replicas)
primary_conninfo = 'host=primary-db.internal user=replicator password=strong-password application_name=replica1'
primary_slot_name = 'replica1_slot'    # Replication slot (primary keeps WAL until replica confirms receipt)
recovery_target_timeline = 'latest'

# Signal the replica to start as standby
touch /var/lib/postgresql/17/main/standby.signal
systemctl start postgresql

---

Read Replica Routing in Your Application

// lib/db.ts — primary/replica routing with Prisma
import { PrismaClient } from '@prisma/client';

// Separate clients for primary (writes) and replica (reads)
const primaryClient = new PrismaClient({
  datasources: { db: { url: process.env.DATABASE_URL } },
  log: ['error'],
});

const replicaClient = new PrismaClient({
  datasources: { db: { url: process.env.DATABASE_REPLICA_URL } },
  log: ['error'],
});

// Wrapper that routes by operation type
export const db = {
  // Read operations → replica
  users: {
    findUnique: (...args: Parameters<typeof primaryClient.users.findUnique>) =>
      replicaClient.users.findUnique(...args),
    findMany: (...args: Parameters<typeof primaryClient.users.findMany>) =>
      replicaClient.users.findMany(...args),
    // Write operations → primary
    create: (...args: Parameters<typeof primaryClient.users.create>) =>
      primaryClient.users.create(...args),
    update: (...args: Parameters<typeof primaryClient.users.update>) =>
      primaryClient.users.update(...args),
    delete: (...args: Parameters<typeof primaryClient.users.delete>) =>
      primaryClient.users.delete(...args),
    upsert: (...args: Parameters<typeof primaryClient.users.upsert>) =>
      primaryClient.users.upsert(...args),
  },

  // Transactions always go to primary
  $transaction: (...args: Parameters<typeof primaryClient.$transaction>) =>
    primaryClient.$transaction(...args),

  $executeRaw: (...args: Parameters<typeof primaryClient.$executeRaw>) =>
    primaryClient.$executeRaw(...args),
};

Important caveat: After a write on the primary, a subsequent read from the replica may not see the new data yet (replication lag). For reads that must be consistent with a just-completed write, route them to the primary:

// After writing: read from primary to avoid stale replica read
async function createOrderAndReturnFresh(data: CreateOrderData): Promise<Order> {
  const order = await primaryClient.orders.create({ data });

  // Read from PRIMARY (same connection guarantees fresh data)
  // If you read from replica, you might get stale data for ~100ms
  return primaryClient.orders.findUnique({ where: { id: order.id } })!;
}

---

Monitoring Replication Lag

-- On primary: check replica lag
SELECT
  application_name,
  state,
  sent_lsn,
  write_lsn,
  flush_lsn,
  replay_lsn,
  -- Lag in bytes
  (sent_lsn - replay_lsn)::bigint AS replay_lag_bytes,
  -- Lag in time
  write_lag,
  flush_lag,
  replay_lag
FROM pg_stat_replication;

-- On replica: check own lag
SELECT
  now() - pg_last_xact_replay_timestamp() AS replication_lag_seconds,
  pg_is_in_recovery() AS is_replica,
  pg_last_wal_receive_lsn() AS received_lsn,
  pg_last_wal_replay_lsn() AS replayed_lsn;

// lib/replication-monitor.ts — alert on high lag
export async function checkReplicationLag(): Promise<void> {
  const result = await primaryClient.$queryRaw<Array<{ replay_lag_bytes: number; application_name: string }>>`
    SELECT application_name, (sent_lsn - replay_lsn)::bigint AS replay_lag_bytes
    FROM pg_stat_replication;
  `;

  for (const replica of result) {
    const lagMB = replica.replay_lag_bytes / (1024 * 1024);

    if (lagMB > 100) {
      await alerting.send({
        severity: 'warning',
        title: `Replica ${replica.application_name} lag: ${lagMB.toFixed(0)}MB`,
        description: 'Replica is falling behind. Check for: slow network, long queries, autovacuum contention.',
      });
    }
  }
}

---

Logical Replication

Logical replication decodes WAL into SQL-level events. Unlike physical replication, it's selective (table-level) and works across major PostgreSQL versions — making it essential for zero-downtime major version upgrades.

-- On source (old version): create publication
CREATE PUBLICATION migration_pub FOR TABLE orders, users, products;

-- On target (new version): create subscription
CREATE SUBSCRIPTION migration_sub
  CONNECTION 'host=old-db.internal user=replicator password=xxx dbname=app'
  PUBLICATION migration_pub;

-- Monitor subscription progress
SELECT
  subname,
  pid,
  received_lsn,
  latest_end_lsn,
  latest_end_time
FROM pg_stat_subscription;

Zero-downtime major version migration steps:

1. Spin up new PostgreSQL 17 instance alongside existing PostgreSQL 15
2. Create schema on new instance (migrations only, no data)
3. Start logical replication: new subscribes to old's publication
4. Wait for replication lag to reach < 1 second
5. Maintenance window (seconds):
   a. Block writes on old instance (set to read-only)
   b. Wait for replication to fully catch up (lag = 0)
   c. Promote new instance to primary
   d. Update DATABASE_URL in app config
   e. Restart app servers
6. Monitor for 1 hour
7. Decommission old instance

---

Automatic Failover with Patroni

Patroni manages PostgreSQL high availability — detecting primary failure and promoting a replica automatically:

# patroni.yml — on each PostgreSQL node
scope: postgres-cluster
name: pg-node-1

restapi:
  listen: 0.0.0.0:8008
  connect_address: 10.0.1.1:8008

etcd3:
  hosts:
    - etcd-1:2379
    - etcd-2:2379
    - etcd-3:2379

bootstrap:
  dcs:
    ttl: 30
    loop_wait: 10
    retry_timeout: 30
    maximum_lag_on_failover: 10485760  # 10MB — don't promote replica with > 10MB lag
    postgresql:
      use_pg_rewind: true
      parameters:
        max_connections: 200
        shared_buffers: 4GB
        wal_level: replica

postgresql:
  listen: 0.0.0.0:5432
  connect_address: 10.0.1.1:5432
  data_dir: /var/lib/postgresql/17/main
  authentication:
    replication:
      username: replicator
      password: strong-password
    superuser:
      username: postgres
      password: postgres-password

# Monitor cluster health
patronictl -c /etc/patroni.yml list
# Member      Host         Role    State   TL  Lag in MB
# pg-node-1   10.0.1.1:5432  Leader  running  3  |
# pg-node-2   10.0.1.2:5432  Replica running  3  0
# pg-node-3   10.0.1.3:5432  Replica running  3  0

# Manual failover (e.g., for maintenance)
patronictl -c /etc/patroni.yml failover postgres-cluster --master pg-node-1 --candidate pg-node-2

---

RDS Multi-AZ vs Read Replicas

For teams on AWS RDS, the two options:

# terraform/rds.tf
resource "aws_db_instance" "primary" {
  identifier        = "app-postgres"
  engine            = "postgres"
  engine_version    = "17.2"
  instance_class    = "db.r6g.large"
  allocated_storage = 100

  multi_az = true  # Creates synchronous standby in different AZ

  backup_retention_period = 7  # Days of automated backups
  deletion_protection     = true
}

resource "aws_db_instance" "read_replica" {
  identifier          = "app-postgres-read"
  replicate_source_db = aws_db_instance.primary.id
  instance_class      = "db.r6g.large"
  # No storage needed — derived from source
}

---
