Advanced Caching Strategies: Write-Through, Write-Behind, Cache Stampede Prevention, and Redis Cluster

Most teams implement cache-aside (read from cache; miss → fetch from DB → write to cache) and call it done. That works for simple cases but falls apart under high load with popular keys, during deployments, and when write patterns matter.

---

The Four Cache Write Patterns

---

Cache-Aside (Most Common)

// lib/cache-aside.ts
import { Redis } from 'ioredis';
import { db } from './db';

const redis = new Redis(process.env.REDIS_URL!);

export async function getUser(userId: string): Promise<User | null> {
  const cacheKey = `user:${userId}`;

  // 1. Check cache
  const cached = await redis.get(cacheKey);
  if (cached) return JSON.parse(cached);

  // 2. Miss → fetch from DB
  const user = await db.users.findUnique({ where: { id: userId } });
  if (!user) return null;

  // 3. Populate cache (TTL: 5 minutes)
  await redis.setex(cacheKey, 300, JSON.stringify(user));

  return user;
}

// Invalidate on write
export async function updateUser(userId: string, data: Partial<User>): Promise<User> {
  const user = await db.users.update({ where: { id: userId }, data });
  await redis.del(`user:${userId}`);  // Invalidate cache
  return user;
}

Weakness: After invalidation, the first read triggers a DB query. Under high load, many concurrent readers can all miss and all query the DB simultaneously — the cache stampede problem.

---

Write-Through Cache

// lib/write-through.ts
// Write to cache and DB atomically (or near-atomically)

export async function updateUserWriteThrough(userId: string, data: Partial<User>): Promise<User> {
  const user = await db.users.update({ where: { id: userId }, data });

  // Write to cache immediately after DB write
  // Cache is always up-to-date after writes
  const cacheKey = `user:${userId}`;
  await redis.setex(cacheKey, 300, JSON.stringify(user));

  return user;
}

// Read: almost always a cache hit (since writes populate cache)
export async function getUserWriteThrough(userId: string): Promise<User | null> {
  const cached = await redis.get(`user:${userId}`);
  if (cached) return JSON.parse(cached);

  // Only misses on first read or after Redis flush
  const user = await db.users.findUnique({ where: { id: userId } });
  if (user) {
    await redis.setex(`user:${userId}`, 300, JSON.stringify(user));
  }
  return user;
}

---

Cache Stampede Prevention

The stampede problem: a popular cache key expires, and thousands of concurrent requests all miss the cache and hit the DB simultaneously.

Solution 1: Mutex lock (one reloader at a time)

// lib/cache-with-lock.ts
import { Redis } from 'ioredis';

const redis = new Redis(process.env.REDIS_URL!);

export async function getWithLock<T>(
  key: string,
  ttlSeconds: number,
  fetchFn: () => Promise<T>,
): Promise<T> {
  // Check cache first
  const cached = await redis.get(key);
  if (cached) return JSON.parse(cached) as T;

  const lockKey = `lock:${key}`;
  const lockTTL = 10;  // 10-second lock — if reloader hangs, lock expires

  // Try to acquire lock (SET NX = only if not exists)
  const locked = await redis.set(lockKey, '1', 'EX', lockTTL, 'NX');

  if (locked) {
    // We have the lock — fetch and populate cache
    try {
      const data = await fetchFn();
      await redis.setex(key, ttlSeconds, JSON.stringify(data));
      return data;
    } finally {
      await redis.del(lockKey);
    }
  } else {
    // Another process is reloading — wait briefly and retry from cache
    await new Promise(resolve => setTimeout(resolve, 50));
    const retryCache = await redis.get(key);
    if (retryCache) return JSON.parse(retryCache) as T;
    // If still no cache, fetch directly (avoids deadlock)
    return fetchFn();
  }
}

Solution 2: Probabilistic Early Expiration (XFetch algorithm)

Instead of all requests stampeding at expiry, each request has a small probability of reloading before expiry, based on remaining TTL and recomputation cost:

// lib/early-expiration.ts
// XFetch: probabilistic early cache refresh — avoids stampedes entirely

interface CachedValue<T> {
  data: T;
  fetchDurationMs: number;  // How long it took to compute this value
  expiresAt: number;        // Unix timestamp (ms)
}

export async function getXFetch<T>(
  key: string,
  ttlSeconds: number,
  fetchFn: () => Promise<T>,
  beta: number = 1.0,  // Higher beta = more aggressive early refresh
): Promise<T> {
  const raw = await redis.get(key);

  if (raw) {
    const entry: CachedValue<T> = JSON.parse(raw);
    const now = Date.now();
    const remainingMs = entry.expiresAt - now;

    // XFetch formula: refresh early with probability based on:
    //   - How long the value took to compute (fetchDurationMs)
    //   - How close we are to expiry
    //   - Beta parameter (tuning knob)
    const shouldRefreshEarly =
      -entry.fetchDurationMs * beta * Math.log(Math.random()) >= remainingMs;

    if (!shouldRefreshEarly) {
      return entry.data;
    }
    // Fall through to refresh (this request does it; others still get cached value)
  }

  // Fetch fresh data, recording how long it takes
  const start = Date.now();
  const data = await fetchFn();
  const fetchDurationMs = Date.now() - start;

  const entry: CachedValue<T> = {
    data,
    fetchDurationMs,
    expiresAt: Date.now() + ttlSeconds * 1000,
  };

  await redis.setex(key, ttlSeconds, JSON.stringify(entry));
  return data;
}

---

Tag-Based Cache Invalidation

When you need to invalidate a group of related cache keys (e.g., "all cache entries for tenant X"):

// lib/tag-cache.ts
// Store cache keys by tag for group invalidation

export async function setWithTags(
  key: string,
  value: unknown,
  ttlSeconds: number,
  tags: string[],
): Promise<void> {
  const pipeline = redis.pipeline();

  // Store the value
  pipeline.setex(key, ttlSeconds, JSON.stringify(value));

  // Register the key under each tag (using Redis sets)
  for (const tag of tags) {
    pipeline.sadd(`tag:${tag}`, key);
    pipeline.expire(`tag:${tag}`, ttlSeconds * 2);  // Tags expire after double the value TTL
  }

  await pipeline.exec();
}

export async function invalidateTag(tag: string): Promise<void> {
  const keys = await redis.smembers(`tag:${tag}`);
  if (keys.length === 0) return;

  const pipeline = redis.pipeline();
  for (const key of keys) pipeline.del(key);
  pipeline.del(`tag:${tag}`);
  await pipeline.exec();
}

// Usage:
await setWithTags(
  `user:${userId}:profile`,
  userProfile,
  300,
  [`user:${userId}`, `tenant:${tenantId}`],
);

// When user is updated — invalidate all their cache entries
await invalidateTag(`user:${userId}`);

---

Redis Cluster for Scale

A single Redis instance handles ~100K ops/second and up to ~100GB of data. When you exceed this, use Redis Cluster:

Redis Cluster: 6 nodes (3 primary + 3 replica)
  - Primary 1: hash slots 0–5460      (keys: a, b, c... hashing to these slots)
  - Primary 2: hash slots 5461–10922
  - Primary 3: hash slots 10923–16383
  Each primary has one replica for failover

// lib/redis-cluster.ts
import { Cluster } from 'ioredis';

export const redis = new Cluster([
  { host: 'redis-node-1', port: 6379 },
  { host: 'redis-node-2', port: 6379 },
  { host: 'redis-node-3', port: 6379 },
], {
  redisOptions: {
    password: process.env.REDIS_PASSWORD,
    tls: {},  // TLS required in production
  },
  // Read from replicas (reduces read load on primaries)
  scaleReads: 'slave',
  // Retry on MOVED/ASK redirects (cluster resharding)
  maxRedirections: 16,
});

// Important: multi-key operations (MGET, pipeline) require keys in the same slot
// Use hash tags to force related keys to same slot:
// user:{123}:profile and user:{123}:sessions both hash to slot of "123"
const userId = '123';
const profileKey = `user:{${userId}}:profile`;   // Hash tag: {123}
const sessionsKey = `user:{${userId}}:sessions`; // Same hash tag: {123}
// These are guaranteed to be on the same cluster node → pipeline safe

const pipeline = redis.pipeline();
pipeline.get(profileKey);
pipeline.get(sessionsKey);
const [profile, sessions] = await pipeline.exec();

---

Cache Metrics to Monitor

// Track cache hit rate and latency in production
export async function getWithMetrics<T>(
  key: string,
  fetchFn: () => Promise<T>,
  ttl: number,
): Promise<T> {
  const start = Date.now();
  const cached = await redis.get(key);
  const cacheLatency = Date.now() - start;

  if (cached) {
    metrics.increment('cache.hit', { key_prefix: key.split(':')[0] });
    metrics.timing('cache.latency', cacheLatency);
    return JSON.parse(cached) as T;
  }

  metrics.increment('cache.miss', { key_prefix: key.split(':')[0] });

  const dbStart = Date.now();
  const data = await fetchFn();
  metrics.timing('cache.db_fetch_latency', Date.now() - dbStart);

  await redis.setex(key, ttl, JSON.stringify(data));
  return data;
}

// Alert if hit rate drops below 80%
// Cache hit rate = cache.hit / (cache.hit + cache.miss)

---
